| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | T/T,Paypal,Western Union |
| Prod Model: | TEM82E |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Conductivity: | ≥5 U S/Cm |
| Rated Pressure: | 0.6, 1.0, 1.6, 2.5, 4.0,6.4 MPa |
| Power Supply: | AC:85V~265V, DC:18V~38V |
| Signal Output: | 4-20mA,Pulse,RS-485, Hart. |
| Electrode Material: | 316L, PT, Ta, Ti, Hb, Hc, Wc |
| Converter Type: | Integral, Remote |
| Protection Grade: | IP67/IP68 |
| Explosion Proof: | Ex Deibmb Iic T3~6 |
| Liner: | PU/ F4/ F46(FEP)/ PFA(Dn10~30) |
| Electrode Number: | 3~6 PCS |
| Type: | Electromagnetic Flow Meter |
| Measuring Principle: | Electrical Principles |
| Measuring Media: | Liquid |
| Main Application: | Slurry,Sea Water |
| Sensor: | Tube/Flange |
| Accuracy: | +-0.25%, +-0.5% (Upon Req.) |
| Size: | 6 to 2800mm |
| Product name: | Electromagnetic flow meter |
| Model Number: | TEM82E |
| Size: | DN6~DN2800 |
| Medium: | Conductive liquid, slurry |
| Medium Temperature: | E grade∠60°C.H grade∠180°C |
| Conductivity: | ≥5 u S/cm |
| Accuracy: | ±0.25% . ±0.5% |
| Repeatability: | ±0.1% . ±0.17% |
| Rated Pressure: | 0.6, 1.0, 1.6, 2.5, 4.0, 6.4 MPa (or specified by customer ) |
| Display : | Instantaneous flowrate, total flow, velocity, flowrate percentage with back light |
| Signal Output: | 4-20mA current output, pulse output, pulse output, RS-485, Hart. |
| Power Supply: | AC:85V~265V, DC:18V~38V |
| Converter Type: | Integral, remote |
| Protection Grade: | IP67/IP68 |
| Explosion Proof: | Ex deibmb IIC T3~6 |
| Velocity: | 0.05~12m/s ( 0.1~15m/s as required ) |
| Liner: | PU(DN25~DN500)/ F4(PTFE) (DN25~DN1600)/ F46(FEP) (DN10~DN200)/ PFA (DN10~30) |
| Flowing Direction: | Forward, Reverse |
| Electrode Material: | 316L, Pt, Ta, Ti, HB, HC, WC |
| Electrode Number: | 3~6 pcs |
| Flange Material: | SS/CS |
| Alarm (normal open): | Empty, excitation, upper/lower limit |
| Ambient: | Temperature: -30~+60°C, Humidity: <90% |
| Protocal: | RS-485/ Hart |
| Product package details | |
| Packing | 1.Carton 2.Woode Case 3.pallet pvc water flow meter |
| Mini order quantity | 1 set |
| Product payment terms | |
| 1) Accepted small order:1 set | |
| 2) Ready to ship out within by sea, TNT, DHL, FedEX, as soon as we receive payment. | |
| 4) We accept T/T. Western Union. | |
| Product Warranty | |
| Warranty | 18 Month's Warranty |
| Our warranty | 1. We offer 18 Month's Warranty on all product free of charge(EVEN EXPIRED FOR WARRANTY PERIOD WE ALSO OFFER YOU FREE,THIS DEPENDS ON the REAL SITUATION) ,but the user should be responsible for one -way transportation fee from the customer to the factory. |
| 2.We offer instrument installtion for customer,and the charges will be made according the cost ,for any hardware failure of the instrument ,we recommend customer send back the instrument to us for service,due to the fact that the instrument is made of microprocessors and it will be difficult to perform field maintenance,Before sending back the instrument ,please try to contact us first to make sure what the problem is. for other operational problem.please contact our service department by telephone,fax,or email and internet ,in the most cases,the problem should be solved immediately . | |
