Screw Compressor 20HP
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Product Specifications
| Prod Model: |
LW-20 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Screw |
| Power Source: |
AC Power |
| Configuration: |
Stationary |
| Lubrication Style: |
Lubricated |
| Application: |
Air Cleaning, Blowing Dust, Sandblasting |
| Color: |
Any Color in Pantone Code Is Available. |
| Brand: |
OEM Can Be Provided. |
Product Description
1. Reliable quality, new low attractive price since Apr. 2013
2. German Air end, 20 years manufacture experience
3. Perfect service network
4. Easy to install, operate, maintain.
5. Low noise and engergy consumption as well as Low maintainence cost.
6. Intelligent Control, PLC control, LCD displayer.| Model | LW-10 | LW-15 | LW-20 | LW-30 | LW-40 | LW-50 | LW-60 | LW-75 | LW-100 | LW-125 |
| TYPE OF COOLING | air cooling |
| AIR DELIVERY/DISCHARGE PRESSURE (M3/MIN/MPA) | 1.2/0.7 | 1.8/0.7 | 2.0/0.7 | 3.6/0.7 | 4.9/0.7 | 6.1/0.7 | 7.2/0.7 | 10.3/0.7 | 13.3/0.7 | 16.3/0.7 |
| 1.1/0.8 | 1.6/0.8 | 1.8/0.8 | 3.4/0.8 | 4.6/0.8 | 5.8/0.8 | 7.0/0.8 | 9.6/0.8 | 12.3/0.8 | 15.2/0.8 |
| 0.9/1.0 | 1.4/1.0 | 1.6/1.0 | 3.0/1.0 | 4.0/1.0 | 5.1/1.0 | 6.8/1.0 | 8.5/1.0 | 10.9/1.0 | 13.6/1.0 |
| 0.7/1.2 | 1.2/1.2 | 1.4/1.2 | 2.6/1.2 | 3.6/1.2 | 4.6/1.2 | 6.0/1.2 | 7.6/1.2 | 9.8/1.2 | 12.3/1.2 |
| DISCHARGE TEMPERATURE(C0) | WORKING TEMPERATURE:BELOW+150C |
| LUBRICANT(L) | 12 | 16 | 16 | 22 | 26 | 26 | 26 | 54 | 54 | 60 |
| OIL CONTENT IN AIR | ≤3-5ppm |
| NOISE LEVEL | 70-72±2dB(A) | 72-78±3dB(A) |
| TYPE OF DRIVE | BELT |
| SET PRESSURE OF SAFTY VALVE | exhaust pressure+0.1Mpa |
| MOTOR | POWER(KW) | 7.5 | 11 | 15 | 22 | 30 | 37 | 45 | 55 | 75 | 90 |
| STARTING METHOD | STAR DELTA STARTER |
| VOLTAGE/FREQUENCY | 380V-50HZ |
| ISOLATION GRADE | GRADE |
| DIMENSION | LENGTH(MM) | 650 | 830 | 1150 | 1400 | 1700 | 1860 | 2100 |
| WIDTH(MM) | 870 | 1000 | 950 | 1150 | 1400 | 1500 | 1550 |
| HEIGHT(MM) | 1200 | 1290 | 1430 | 1600 | 1800 | 1800 | 2000 |
| NET WEIGHT(KG) | 330 | 450 | 450 | 675 | 1045 | 1075 | 1150 | 1500 | 1600 | 2480 |
Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with the best quality at the reasonable price.
