Screw Sand Washer Machine
| Price: |
US $ 5000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
Screw Sand Washer Machine :1.Big processing capacity and low power consumption
2.Small material loss after washing, high washing and selecting efficiency
3.Reasonable structure and stable operation
4.Low failure rate, easy repairing
5.Saving water resource, without pollution
6.Long service life and no necessity of repair for a long time
Spiral/screw sand washing machine Suitable material:The product of this series is a high-efficiency bucket type sand washer developed and produced according to actual situations of Chinese sandstone industry. Cooperating with sand maker and having functions of cleaning, dewatering and grading, it can remove impurities (such as dust) in sand product.
Screw Sand washing machine /screw sand washer working principle:
The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel. The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other. The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder. On one hand, water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task. Technical Data of the spiral sand washing machine:| Model | Spiral diameter(mm) | Trough length(mm) | Capacity(t/h) | Power(kW) | Overall dimension L×W×H(mm) | Weight(t) |
| XSL0550 | 500 | 5000 | 10-20 | 3 | 6540×1220×1630 | 2.5 |
| XSL0765 | 750 | 6500 | 20-50 | 5.5 | 8380×1570×1920 | 4.3 |
| XSL1075 | 1000 | 7500 | 50-80 | 7.5 | 9550×1920×2270 | 6.7 |
| XSL1275 | 1200 | 7500 | 70-110 | 11 | 9700×2320×2660 | 10.8 |
| XSL1585 | 1500 | 8500 | 90-130 | 18.5 | 11000×2830×3150 | 13.7 |
| XSL1885 | 1800 | 8500 | 110-150 | 22 | 11100×3320×3620 | 15.4 |
| XSL2085 | 2000 | 8500 | 130-170 | 22 | 11340×3670×3880 | 19 |
Contact: Ms Sara
Mobile phone): 008613783471727
| Prod Model: |
dia500-dia2000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Spiral Sand Washing Machine Usage: |
Washing Dirty, Clay in The Sand |
| Spiral Sand Washing Machine Colour: |
as Request |
| Spiral Sand Washing Machine Model: |
XL508-XL1118 |
| Spiral Sand Washing Machine Type: |
Single and Double Drum |
| Spiral Sand Washing Machine Voltage: |
380/220V |
| Max Feeding Size: |
3-10mm |
| Overall Dimensions: |
Depending on Model |
| Weight: |
Depending on Model |
| Warranty: |
One Year |
| Name: |
Spiral Sand Washing Machine |
| Type: |
Spiral Sand Washer |
| Motor Type: |
AC Motor |
| Capacity: |
5-200t/H |
Henan LanJi Machinery Manufacturing Co., Ltd. is a jiont-stock mining machinery manufacturing enterprises integrated in scientific research, production and marketing. It is located at the Hig-Tech development Zone Zhengzhou, China with an area of 80 thousand square meters. Equipments are more than 200 pieces, including large and medium sized metal processing, riveting and installing equipments. Engineers are more than 50 persons.
The leading products of our company include: Beneficiation equipment, crushing equipment, sand making equipment, cement equipment, Aerated concrete block production line. Widely used in the industries of metallurgy, mining, railway, high-way, building materials, refactory, ceramic industry, etc. Complete set of ore beneficiation equipment include ball mill, crusher, magnetic separator, flotation machine, spiral classifier, rotary dryer, widely used to separate the non-ferrous metals such as iron ore, copper ore, gold ore, lead&zinc, manganese ore, molybdenum ore, etc. And the Non-metallic Minerals like fluorite, quartz, etc. Jaw crusher, impact crusher, sand making machine, vibrating screen, sand washing machine, belt conveyor are widely used for the airport, railway, high-way, road, buliding, etc. Aerated concrete block has been one important part to the new buliding materials. We can provide program design, process flow design, standard and non-standard design for clients.
Our company has passed ISO9001-2008 quality certificate, the produce sell well to domestic and abroad, Such as South Asia, Russia, Central Asia, Africa, Middle-east, etc.
Our company's tenetis "Advanced technology, quality first, sincere service, reputation first". We can ensure our clients without worry after buying by one set of complete after-sales service and quality-tracking system.
We sincerely hope to cooperate with the clients from all over the world to achieving mutual benefits and promotion, ans touching our theory through cooperation!
