Screw Terminal Blocks Euro connector？
Pitch: 5.0mm
Material:
Screws: M2.5 steel Zinc plated
Wire guard: Phosphor bronze Ni plated
Or stainless steel
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0
Electrical:
Rated voltage: 300V
Rated current: 15A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ /1000V
Withstanding voltage: AC1500V/1Min
Wire Range: 28-12AWG 0.5-2.5mm²
Mechanical:
Temp Range: -40º C~+105º C
Max Soldering: +250º C, for 5Sec.
Torque: 0.4Nm(3.6lb. In)
Strip length: 5-6mm
Datasheet of？Screw Terminal Blocks？
