Main Application:
Our SF40 Pulverizing Machine has wide application, it's wide used for pharmaceutical industry, chemical industry foodstuff industry, grain industry and so on.
Working Principle:
This SF40 Pulverizing Machine uses the relative motion between movable and fixed fluted discs, the raw materials to be crushed undertakes the comprehensive actions such as impacted by teeth, friction, impacted between raw materials are crushed. Its features are simple and solid in structure, stable in operation, high crushed efficiency. The crushed raw material can be discharged through the grinding chamber. Moreover, different size of raw material to be crushed can be got through exchanging screen with different mesh.
It's inner wall is processed finely, so it is smooth and level, all the parts in the chamber which contact materials surficial parts are made of stainless steel, it's in conformity with the requirements of state standard and meet the requirements of GMP
According to customer needs, may increase water cooling device and conveyer screw.
Technical Parameters:
Model: SF40
Capacity(kg/h): 160-800
Spindle speed(r/min): 3400
Feeding size(mm): 12
Crushing Fineness(mesh): 60-120
Power of motor(kw): 11
Overall size(mm): 800*900*1500
Weight(kg): 510.
