| Price: | US $ 30000-60000/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: | SD23 |
|---|---|
| Markets: | North America,South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Machine Weight: | 24.6 Tons |
| Dimension(Long * Breadth * High): | 5874*3725*3360 |
| Rated Power: | 169kw@2000rpm |
| Engine Model: | Cummins Nt855-C280s10 |
| Walking Mode: | Crawler |
| Certification: | ISO9001: 2000 |
| Condition: | New |
| Type: | Bulldozer |
1.Rated Power: 169kW@2000rpm
2.Engine Model: Cummins NT855-C280S10
3.Operating Weight: 24.6 T
Keeping the excellent technology and reliability of the original SD23, Shantui has adopted international advanced technology to enhance the SD23E and give it better maneuverability. Shantui has installed imported components to what used to some of the machines weaker parts, thereby creating a new generation of Shantui products.
| ITEM | UNIT | SD23 |
|---|---|---|
| L×W×H (Ripper not included) | mm | 5874×3725×3360 |
| Operating weight (Ripper not included) | t | 24.6 |
| Engine | - | Cummins NT855-C280S10 |
| Rated power | kW/rpm | 169/2000 |
| Gradeability | ° | 30 |
| Blade type | - | Straight tilt bladeU-bladeAngle blade |
| Blade width | mm | Straight tilt blade 3725×1395U blade3860×1379 Angle blade4365×1107 |
| Dozing capacity | m 3 | Straight tilt blade 7.8 U blade 8.4Angle blade 5.4 |
| Ma× drop below ground of blade | mm | 540 |
| Lift height of blade | mm | 1210 |
| Ripper type | - | Single ripperThree-shank ripper |
| Ripping depth of ripper | mm | Single ripper 695Three-shank ripper 666 |
| Lifting height of ripper | mm | Single ripper 515 Three-shank ripper 555 |
| Number of carriers (each side) | - | 2 |
| Number of track rollers (each side) | - | 7 |
| Number of track shoes (each side) | - | 39 |
| Width of track shoe | mm | 560/610/660 |
| Track gauge | mm | 2000 |
| Ground length and ground pressure | mm/MPa | 2840-0.078 |
| Pitch | mm | 216 |
| Forward speed | km/h | 0–3.8 |
| 0–6.8 | ||
| 0–11.8 | ||
| Reverse speed | km/h | 0–4.9 |
| 0–8.5 | ||
| 0–14.3 |
