1,Mainly technial specification
Model
| HS23 |
Resistance value
| 2.2micro ohm |
Max current
| 25A |
Thickness
| 0.5mm |
Dimension
|
34*30*5mm
|
2,Application:
1),Serving in all kinds of electrical meters
2),energy meters
3),measurement instruments as power measurer.
3. Electrical specification:
1) Material: F2 or 6J13 Manganin and pure copper.
2) Welding mode: Electro-beam welding.
3) Resistance value tolerance: 2.2micro ohms ± 5%
4) Shunt type: The shunt should be mountable type with holes for screw fixing
5) Termination: Integrated lead wires are available.
6) Temperature: Independent from temperature variation with low TCR value.
7)Characteristics TC < 50PPM/K
8) Power loss: < 50 milli watt
9) Aging: 10 hours under 120 deg.
10) Customized designs are available against customers' drawings/samples.
11), Top quality with low price
