USB flash disk cover micro injection machinery
Specifications
1.PVC dispensing machine
2.Fully automatic operation
3.Dripping process programmable
4.Energy and labor saving
5.CE and SGS
6.material:PVC,silicone,ink
7.high speed
8.suit for multiple-colors
9.easy to operate
10.USB flash disk cover micro injection machinery
Main advantages:
1. Full-automatic processed by PLC, operate easily and accurately
2. Max 8 colors to work at one time, there is no time interval between color change so as to improve the high efficiency result
3. One stuff can operate several dripping machines and molds at one time.
4. Four different procedures to choose from the touching operate button
5. Store hundreds of procedures in total, every time you can choose four of them to be remembered by the operate plate and no need to reset the procedure
6. Without drop and leak and cost saving
7. time and labor saving, an experienced technical can operate 3-4 machines cat the same time
8. Produce 8-20 products in the same color at one time
9. Take up just a small place
10. Different workable size for choice
11. Suitable for a wide range of products
12. This product has passed CE certificate
USB flash disk cover micro injection machinery operation:
1.Labor saving, improve the production efficiency, one automatic dispensing machine can replace 4-6 skilled workers, one worker can operates several sets machines, greatly saving labors, some workers can do as dozens of workload, cut down the production phase. Solve the problems of labor shortage, more hard for practiced hand, hard manage, plant cover large, high input cost
2. Special software, easy operation, multi-needles multi-colors, dropping accuracy. 8-12 colors(can extensible to 16 needles), multi needles can dispensing at the same time.
3. High precision, fast and liquidity walk in arc, three-dimensional. Coordinated system control, the precision can be 0.01mm, the products it produced is very stabilized, the products present of pass can over 99.9%, can improve the working efficiency 200-800%.
4. High stability: adopts CNC engraving machine rack construction technology, the materials adopts cast iron and granite, the rack will not be out of shape in 5-8 years, adopts origional imported screw rod, electrical equipment, moving stability and reliable, low failure rate.
5.USB flash disk cover micro injection machinery guideline: to make the dispensing machine working in high efficiency, must do as follows:
(1) worker: using our dispensing machine, is to liberation the workers out of the boring and repeat dispensing training part.
(2) The workers main job is changed from dispensing and drying mold to control the machine production. The workers just need careful, strong sense of responsibility, the workers can take up
Specification:
| Model No.: | LX-P800 |
| Type: | 4/6/8/12 color |
| Work Journey: | L400*W500*H600MM |
| Dimension: | L1100*W1000*H1500MM |
| Weight: | 80KG |
| Power: | 250W |
| voltage: | 220W |
| Transmission Method: | Ball screw |
Company introduction:
Guangdong Li Xin Intelligent Technology Co.,Ltd. Is focus on providing customer with comprehensive support of PVC& Silicone trademark & products machinery more than 20 years. Product win more than 10 technology patent, passed certificate wtih CE, SGS. Do have own foreign office to work together, Customer first, helping and implement customers idea is our mission.we are sincerely welcome you to visit our factory and have more business communication.
Main products:
1. PVC automatic production line:most advanced Injection and dripping machine, Semiautomatic and Full-automatic type.
2. Liquid silicone brand shaping machine (6 work heads, automatic processing, fast speed and durable quality)
3. Solid silicone brand shaping machine(30% energy saving, high efficiency, one step finished)
4. Silicone three-dimensional printing machine, Silicone lace coating machine, pre-shrinking machine---all automatic type with Unique patent.
5. Support equipment (Engraving machine,Vacuum machine, baking oven,cooling machine etc.)
6. Your idea, we made, Lixin is your best choice.
Package & delivery& payment.
1. Package: Seaworthy wooden case packages.
2. Delivery: max 30days after order confirmed.( If have stock, 2 days is ok ).
3. Payment: 30%T/T in advance as deposit, 70% T/T before shipment. L/C is acceptable for special area or country.
Our service:
Pre sales:
1. Provide free solution for your production with suitable machinery combination.
2. EX-work price with most competitive strength.
3. Enjoy Endurable quality of machinery and professional training service.
4. Visiting our factory for checking or training is welcome.
After-sales:
1. Warranty: 1 year.(except manmade damage and consumables parts)
2. Free installation & training service.
3. Life-long maintenance service.
FAQ:
1Q:Can you provide technical support?
A: Selection to provide comprehensive technical support, and free technical training.
2Q:What if the machine are defected after we get the machine?
A: One year warranty , Life-long free maintenance and 24 hour online consulting, solution will provided within 48 hours.
3Q:Why choose Lixin Machinery Co.,Ltd.?
A: Our products with more than 30% energy saving. Highest Cost effective environmentally. Excellent pre-sale and after-sale services.
4Q:Are customized products accepted?
A:Your idea, your choice, your idea, we make, Lixin Machinery to be your factory.
USB flash disk cover micro injection machinery Contact us:
Dong Guan Li Xin Machinery Co., LTD
China Factory:Niu Shan Industrial Garden:Dong Chen District,Dong Guan, Guang Dong, China
Tel:+86-769-22664082 22698499 22209643
Fax :+86-769-22669648
Mobile: +86-13790326682
Website: www.gobohk.com
Dongguan Lixin Machinery Co., Ltd. Was founded in early 1990s and is situated in rich East Town of Dongguan City. Our company is a manufacturing and developing enterprise professionally engaged in the field of PVC trade mark and silicone trade mark machinery. For a decade, our company has not only bettered troops and simplified administration in management, but also endeavored to do better in technology. Our company has set up a good reputation within the industry and become the earliest production base of PVC trade mark and silicon trade mark machinery domestically.
Our main products are ultrared ray PVC trade mark moulding ovens, transparent dipping plastic baking ovens, mixing and dispersing machines of raw materials, color matching machines, vacuum defoaming machines, automatic plastic dipping machines, silicone trade mark moulding machines, mould cooling machines and automatic assembly lines. Our products sell well in Egypt, Indonesia as well as Shanghai and Fujian in China...
Quality is the life and efficiency comes from management. With the efforts, we have set up a set of strict quality inspection system and perfect pre-sales and after-sales service measures. We will do our utmost to surpass the expectation of customers, make continuous improvements to ensure sustainable development of our enterprise, let us become a visiting, consulting and training base for new and old customers in PVC microscale injection trade mark and silicone trade mark machinery field.
You make fortune, but let me develop. Let's go forward hand in hand and do our best to make PVC and silicone trade mark industry come to a new height in the new century!
