Application range:
This product is widely applied for storage medium, serum, medicine, environmental testing and etc.
Structural characteristics:
The product adopts international brands of CFC-free eco-friendly compressor, of high efficiency and low
Energy consumption.
The liner is made of mirror stainless steel, adopts semicircular arc transition, shelf can be loaded and adjusted freely, is easy for cleaning inside.
It adopts LCD microcomputer temperature controller, achieve the seting value quickly, and can run more accurate and stable.
It is equipped with RS485 interface for connecting print and computer, to record changes status of temperature parameter.
| Item | Temperature control range | Temperature resolution | Temperature fluctuation °C | Power &Voltage | Working environment temperature | Power(W) | Working room capacity(L) /size(cm) | Outline dimension (cm) | Net/gross weight (KG) |
| Model |
| SPX-80L | L:-10~65 ° C A:-20~65°C B:-40~65°C | 0.1 ° C | High temperature:+/-5°C Low temperature: 1°C | AC220V 50Hz | +5~35°C | 380 | 80/40x37x55 | 54x57x107 | 50/85 |
| SPX-150L | 450 | 150/45x42x85 | 59x62x137 | 90/120 |
| SPX-200L | 500 | 200/45x45x85 | 59x64x152 | 95/138 |
| SPX-250L | 550 | 250/48x49x107 | 62x68x159 | 103/147 |
| SPX-300L | 600 | 300/52x50x117 | 66x69x169 | 115/157 |
| SPX400L | 750 | 400/58x54x127 | 72x74x179 | 135/170 |
| SPX-80A | 380 | 80/40x37x55 | 54x57x107 | 50/85 |
| SPX-150A | 380 | 150/45x42x85 | 59x62x137 | 90/120 |
| SPX-200A | 500 | 200/45x45x85 | 59x64x152 | 95/138 |
| SPX-250A | 550 | 250/48x49x107 | 62x68x159 | 103/147 |
| SPX-300A | 600 | 300/52x50x117 | 66x69x169 | 115/157 |
| SPX-400A | 750 | 400/58x54x127 | 72x74x179 | 135/170 |
| SPX-80B | 380 | 80/40x37x55 | 54x57x107 | 50/85 |
| SPX-150B | 380 | 150/45x42x85 | 59x62x137 | 90/120 |
| SPX-200B | 500 | 200/45x45x85 | 59x64x152 | 95/138 |
| SPX-250B | 550 | 250/48x49x107 | 62x68x159 | 103/147 |
| SPX-300B | 600 | 300/52x50x117 | 66x69x169 | 115/157 |
| SPX-400B | 750 | 400/58x54x127 | 72x74x179 | 135/170 |
Shanghai Hengyue Medical Instrument Co., Ltd., is located in Zabei District, in Shanghai, China, owns two factories, covering an area of 8500 sq. M.
Our products have a good reputation in this industry, is of high prestige, high quality and is reliable. We regards quality management as the life of our company. We have CE Certificate and passed ISO9001: 2008 and ISO: 13485: 2003. We won the honours of ' Contract Observing Creditable Enterprise' And ' Shanghai Medical Instrument Industry Creditable Enterprise' Issued by Shanghai Industry and Commerce Administration Bureau and Shanghai Medical Instrument Industry union.
Shanghai Yuejin Medical Instruments Factory is founded in 1975, is located in Baoshan Distric in Shanghai. And ' Shengguang' Is a very famous brand. The factory is specialized in manufacturing, developing and distributing medical instrument, including Ent diagnostic set, ultraviolet disinfector trolley, ultraviolet air disinfection chamber, infrared therapy lamp, X-ray implement, tending bed, nursing instruments, ultrasonic cleaner, operating table, and etc.
Shanghai Yuejin Medical Instrument Co., Ltd., is founded in1974, I located in Pudong District in Shanghai. And ' Hengzi' Is also a very famous brand. It is specialized in manufacturing, developing and distributing medical instrument, including: Biochemistry incubator, CO2 cell incubator, electrothermal thermostatic incubator, water-insulation electrothermal thermostatic incubator, mould incubator, constant temperature and humidity incubator, mould incubator, medicine stability test chamber, medicine storage refrigerator, blood refrigerator, anaerobic incubator, high/low temperature experimental oven, shaker, multifunctional incubator, resistance furnace, and etc.
