Standard with Airtac Piston
All piston filler made from S/S 304 grade stainless steel and aluminum conforms to GMP
Viscous Liquid Model with stainless steel product hopper
Operated by foot pedal switcher or by automatic timer
With Anti-leaking system
Product suction and dispensing speed adjustable
No-Tools for set-up and adjustment
Sanitary tri-clamp connections easy wash
Quick release nozzle and feed pipe
Small footprint for simple bench mounting
Be able to be equipped with other automatic packaging machine
Most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials
Option:
Festo / SMC Piston
Food and pharmaceutical S/S 316 grade stainless steel contact parts.
Full S/S 316 and aluminum for whole machine
For some viscous liquid, the mixing & heating hopper is option
Standard with electric solenoid control, we have pneumatic solenoid valve to work without electric option at full Pneumatic Driven
Technical Specifications:
Air Consumption: 0.6CBM/H
Air Supply Pressure: 0.4-0.6Mpa
Operation Efficiency: 20-40 bottles per min (depends on product and container size)
Filling Precision: < =± 1%
Dimension & Weight: Variable, depending on the application
Typical application for free flowing liquids: Mineral water, edible oil, juice, ink, detergent, perfume
Typical application for viscous liquids: Ketchup, mayonnaise, cream, butter, jam, honey, shampoo
Filling range:
|
Model |
Types |
Volume Range |
Ounce |
All models include piston filler for liquid or viscous liquid in horizontal, vertical or with moving supporting stand.
Dual heads with capacity of volume plus 2 heads. |
0060 |
05-60ml |
2.02 |
|
0125 |
10-125ml |
4.22 |
|
0250 |
25-250ml |
8.45 |
|
0500 |
50-500ml |
16.90 |
|
1000 |
100-1000ml |
33.81 |
|
2500 |
200-2500ml |
84.53 |
|
5000 |
500-5000ml |
169.07 |
Wenzhou Honor Packaging Machinery Co., Ltd., was set up in 1992. We are dedicated to the development, design, production, processing, marketing of packing machines and related equipment.
With rich manufacturing expertise, we have gained an upstanding reputation in the packing machinery industry. As such, our comprehensive line of packaging machinery is selling well in both domestic and international markets. Moreover, all our persevering efforts are spent on serving customers with the sincerest commitment to excellent quality products and maximizing consumer satisfaction.
We are now seeking new partners in order to expand our market share around the world. If you are interested in any of our products, please feel free to visit our website for more details or contact us directly with your inquiries.
Let's working together, developing together and reach success together!
