MOTOR FESTURES
IP55 enclosure
Class B insulation, Class F availale on request
Low operating temperature
High quality magnet wire
Vacuum varnish impregnation for superior tropic proof insulation
Continuous S1 operaion
Industrial type service factors
Heavy duty ball bearings
High strength cast iron frame
Balanced rotors
Cool running motors
CUSTOMER BENEFITS
Water dust and vermin resistant
Quiet operation
Corrosion resistant
Reliable in country, city or factory environments
Very low vibration
Very low power consumption
Superior life
Suitable for hot enviroments
Low start current and EMC interference
Model Power Current Speed Eff Power factor Starting Torque Starting Current Max Torque Net Weight
HP KW A r. M. P % Rated Torque Rated Current Rated Torque kg
YC80A-2 1/2 0.37 3.7 2880 62 0.73 2.8 6.5 1.8 10
YC80B-2 3/4 0.55 5.3 2880 65 0.73 2.8 6.5 1.8 11
YC80C-2 1 0.75 6.7 2880 68 0.75 2.4 6.5 1.8 13
YC90S-2 1.5 1.1 7.2 2880 73.2 0.95 2.8 6.0 1.8 17
YC90L-2 2 1.5 8.9 2900 79.2 0.97 2.8 7.0 1.8 22
YC100L-2 3 2.2 13.2 2900 78.8 0.96 3.0 6.5 1.8 29
YC80A-4 1/3 0.25 3.4 1450 56 0.60 2.8 6 1.8 10
YC80B-4 1/2 0.37 4.5 1450 60 0.62 2.8 6 1.8 11
YC80C-4 3/4 0.55 6.0 1450 64 0.65 2.8 6 1.8 13
YC90S-4 1 0.75 5.5 1450 73.3 0.93 2.8 6.5 1.8 17
YC90L-4 1.5 1.1 7.8 1450 71 0.90 2.5 6.0 1.8 22
YC100L-4 2 1.5 9.3 1450 79.4 0.92 2.8 7.0 1.8 29
YC112M1-4 4 3 18.4 1450 78 0.95 2.1 6.0 1.8 40
YC112M2-4 5 3.7 22.4 1450 78 0.95 2.1 6.0 1.8
YC132SA-4 4 3 25.2 1450 74 0.73 2.1 6.5 1.8 55
YC132SB-4 5 3.7 30 1450 75 0.74 2.1 6.5 1.8 60
YC132M1-4 7.5 5.5 32.5 1450 85 0.90 2.0 6.5 1.8
YC132M2-4 10 7.5 40 1450 85 0.90 2.0 6.5 1.8
Technical Data ( 220V 50Hz) Model Power Current Speed Eff Power factor Starting Torque Starting Current Max Torque Net Weight
HP KW A r. M. P % Rated Torque Rated Current Rated Torque kg
YCL90S-2 1.5 1.1 7.2 2880 73.2 0.95 2.8 6.0 1.8 16
YCL90L-2 2 1.5 8.9 2900 79.2 0.97 2.8 7.0 1.8 22
YCL100L-2 3 2.2 13.2 2900 78.8 0.96 3.0 6.5 1.8 29
YCL90S-4 1 0.75 5.5 1450 73.3 0.93 2.8 6.5 1.8 13
YCL90L-4 1.5 1.1 7.8 1450 71 0.90 2.5 6.0 1.8 16
YCL100L-4 2 1.5 9.3 1450 79.4 0.92 2.8 7.0 1.8 24
YCL112M-4 3 2.2 13.6 1450 81.6 0.90 2.3 6.5 1.8 37
Fuan Omeik Electric Co., Ltd. is a professional manufacturer of water pumps and electric motors, located in Fuan Electrical Machinery and Appliances Zone, Fuan, Fujian, China and established in 1999. It's a fair integrative company with scientific research, production, and sell, which possesses advance producing and testing equipments and strong technology team. The company always strictly follows the ISO9001 quality management system to manage the production which guarantee of good quality.
In order to meet the challenge of the keen market competition, the company has introduced advanced technology and machinery as well as computerized testing equipment to further improving the quality of the products. The company insists on "survives on high quality and honest with business", Basis on this principle our quality products have been exported old over the world, such as South East Asia, Middle East, Australia, Europe and South America etc.
We are longing for hand in hand cooperation with more friends in the whole world, know that quality product and the the after sale services, altogether create happy future, we are warmly welcome your coming and the support.
