Six color pad printer with conveyor worktable
Application:
Big sized pad printer with rotary, conveying products by rotary type turntable. Products can be continuously six-color printed, Running a circle can finish one time overprint. Comparing with shuttle pad printer, it come to a high steps. It can print bigger products with 6 color with fastly and steady.
It is suitable for printing electronic products, plastic shell, hardware products, stationary, small arts and crafts, logo on the surface of gift and toys.
Function:
1. SCM IC complile action program, kinds of printing model option
2. Auto 4-digit counter built-in, and stat. Printing quantity
3. Airframe adopts coin alloy, and metal coating surface
4. Worktable, printing head and ink tray can be adjusted X. Y. Z direction
5. Sucking ink and the pressure of printing pad can be adjusted independently.
6. Scrapper stroke can be adjusted
7. It has function of leveling ink by sliding automatically on front /back, this can avoid printing ink partial solidification
8. The speed of all the cylinders have an independent regulator intortum
9. Adopts original Japan SMC and Taiwan MINDMAN pneumatic component
10. Each adjustable location has scale logo
11. Unique machine body hold-up design, it is convenient to adjust machine and change steel plate
12. It has the function of forbiding the pad fallen when no air pressure enter into
13. The machine is running fastly, it is steady and low voice
14. Installing auto hot-air system, adjust temperature
Technical parameter:
1. Steel plate size: 100*200mm
2. Printing speed: 1500PCS/Hr
3. Power: 220V/110V 50-60MHz 1000W
4. Air pressure: 5-7BAR
5. Action model option: Fully automatic/semi-automatic/ manual/Self-Programming
6. Start-up method: Panel/foot switches
7. Scraper working style: Pneumatic mechanical valve drives cylinder up and down
8. Scraper pressure control: Pressure regulating valve
9. Front/back distance: 200MM
10. Up/down distance: 75MM
11. Max. Printing area: 80*170MM
12. Central distance between Ink tray: 127mm
13. Repeat prcision: < 0.05MM
14. Rinting workstation: 18 PCS
15. Fixuping clamp method: T-slot table, code pressure compress heavily
16. Choosing the material of clamp: Automobil Putty/ Aluminum/bakelite /plastic/steel
17. Astic fastness style: By wooden bolt
Dongguan Hoystar Printing Machinery Co., Ltd. Integrates design, production, and sale together and has a professional team. We specialize in pad printers, screen printers, screen-stretchers, UV machines, exposure machines and other peripherals. Moreover, we can design and produce non-standard machines according to customers' special requirements.
Our company adopts micro-computer systems to control machines with electrical integration. It ensures safe use and convenient operation and can substitute imported machines. Our company enjoys a high reputation in domestic and international markets for strong technology, advanced processing machines, perfect inspecting solutions, precise quality management systems and excellent after-sales service. Our products sell well in America, Australia, Norway, England, The United Arab Emirates and Egypt.
The range of application of our products is containing kinds of commodity, appliance, auto part, metallic tool, toy, craft and package printing for cigarette, wine and cosmetic.
