Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Technology: |
Infrared Interactive Whiteboard |
| Color: |
White or Black |
| Size: |
60''/72''/78''/82''/88''/108'' |
| Resolution: |
8192*8192 |
| Product Features: |
Multi-Touch, Gesture Recognation |
| Operating System: |
Windows 7, XP, Vista, Mac |
| Language: |
Over 100 Languages |
| Certificate: |
CE, FCC, RoHS, ISO |
| MOQ: |
1 Piece |
| Writing Tool: |
Finger, Pen, Pointer |
| Type: |
Whiteboard |
| Laser Model: |
Red Laser |
Product Description
Smart board for sale
Smart Interactive whiteboard for Children and Business
Tacteasy IR Interactive Whiteboard FEATURES
1. Software
Real two-point writing, support finger/pen writing
The resolution reach 8192*8192; Write the small words clearly and truly
Many gesture recognition functions: Page up/Page down/Erase etc.
No need other driver
Free update for software and firmware
2. Hardware
Aluminum Honeycomb Board: Anti-scratch, Anti-glaring
Aluminum Frame: Good texture, Skillful craft
3. Firmware
Full digital design, Both parallel circuit&: Serial circuit structures design.
ARM processor, High effective algorithm: Accurate positioning
4. Accessories
1) Intelligent Pen Tray
2) Wall Mount Brackets
3) 6m USB Cable
4) User Guide Manual
5) Software CD
6) Mobile height-adjustable floor stand(optional/charged additional)
Other information
1. Exquisite material and manufacturing technique
Adopt the aluminium honeycomb as the basic plate which makes the board much more
Flatter, reliable, durable. It also makes writing smoother with ink pens and wiping without any mark. Nano Coating technology makes boards serve dual purpose. At last the outer frames adopt aluminum wiredrawing technology, good texture, and skillful craft. All of these technologies make sure the whiteboard can be used for over 5- 8 years.
2. Touch and gestures-recognition
Perform mouse functions with your finger, and write, erase digital ink with a pen tray or eraser. The object awareness feature enables you to pick up a digital pen, to write, select or erase at your willing. This interactive whiteboard also features gesture capability, providing a natural and flexible way to interact with content.
3. Many solutions possible
Integrate with voting system, wireless tablet and visualizer. Actualize ideas of the interactive classes to make the teachers and students really interactive.
4. Pen tray
Removable end caps for optional accessories. Optical sensors in the pen tray detect when a pen or eraser is lifted from the tray. Color buttons on the pen tray enable you to select different pen color.
Specifications of smart board for sale
|
Basic Data
|
Accessories |
|
Boards Material |
Aluminum Honeycomb |
Pen and pointer |
Yes |
|
Induction Type |
infrared |
TACTEASY Software CD |
Yes |
|
Writing Type |
finger or pen |
USB Cable |
Yes |
|
Positioning Accuracy |
≤ 0.2mm |
User Guide Manual |
Yes |
|
Touch Preciseness |
8192*8192 |
Wall Mount Brackets |
Yes |
|
Cursor Speed |
≥ 125dots/second |
stand |
optional |
|
Scanning Rate |
first point 25m/s consecutive points 8ms |
Hardware Features
|
|
Transferring Rate |
12m/s |
Device driver version |
DL-USB |
|
Consumption Current |
≤ 100mA |
Scanning form |
Auto start, always scanning |
|
Stand USB Length |
6m |
Version |
Latest available |
|
Working Environment |
Direct under the sunlight |
DataPort |
USB /wireless RF2.4G/RS232 |
Dimensions
|
|
Model |
Scale |
Outline Area (mm) |
Touch Area (mm) |
|
TE-6860 |
4: 3 |
1369*1031 |
1230*902 |
|
TE-8072 |
4: 3 |
1612*1202 |
1476*1066 |
|
TE-8072W |
16: 9 |
1776*1038 |
1640*902 |
|
TE-8878 |
4: 3 |
1779*1366 |
1640*1230 |
|
TE-8878W |
16: 9 |
1858*1120 |
1722*984 |
|
TE-9688 |
4: 3 |
1940*1530 |
1804*1394 |
|
TE-9688W |
16: 9 |
2104*1284 |
1968*1148 |
|
TE-116108W |
16: 9 |
2514*1530 |
2378*1394 |
Recognized as one of the leaders in the filed of interactive whiteboard, Tacteasy is offering the most competitive products and solutions for education & training, conferencing, business and government. Tacteasy is developing, manufacturing and selling interactive whiteboard, IR touch Frame touch TV/PC all in one.
After years' development, Tacteasy has owned Scientific regulation system, innovative R&D team and effective production lines. with the increasing of presentation tools, our interactive applications, especially the dual-user infrared interactive whiteboards are in demand and in popularity for educators who want to involve their students and worker in learning technology; It is a lover for education in 21st.
Accompany with Tacteasy, to be a Tacteasy, our aim is to meet and exceed the needs for you. This will result in long term and mutual-benefits relationship with clients all over the world.
