Product Specifications
| Prod Model: |
US1A US1B US1D US1G US1J US1K US1M |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Specifications
SMD super fast diode US1A-US1M
Features:
1)High Efficience,low forward voltage
2)High quality,competitive price
3)More than 40years manufacturing experience
Product discription: 1.0A Surface Mount Super Fast Rectifier US1M
Product Name: Super Fast Rectifier
1)Part Number: US1M
2)Maximum Recurrent Peak Reverse Voltage VRRM: 1000V
3)Maximum RMS Voltage: 700V
4)Maximum Average Forward Rectified Current IAV: 1.0A
5)Peak Forward Surge Current IFSM: 30A
6)Maximum Instantaneous Forward Voltage VF: 1.7V
Maximum DC Reverse Current IR: 5.0uA
Maximum Reverse Recovery Time TRR: 75nS
Super Fast Rectifier: US1M
Features:
For surface mounted application
Low profile package
Built-in strain relief
Ideal for automated placement
Easy pick and place
Daya Electronics Co., Ltd. is specializing in the production of Diodes, Bridge rectifiers, Transistors as a sino-foreign joint venture. Estabished in 2001, the factory is located in XinXiang of Henan province, a convinient traffic high-tech development zone. The area of the plant is more than 20, 000 square meters, the staffs in our company are more than 800, including all types of professional and technical personnel of which researchers accounting for 20 percent or more. We adopt modern clean plants and completed power system. There is a 1000V high-voltage power distribution plant, a gas-making station with 80 cubic meters per hour and a water supply station with one cubic meter per hour. To fully meet the discrete semiconductor devices and the production process requirements, international advanced production, testing equipment and technology are introduced. Annual production capacity would be 3 billion, and 70 percent of the products export to North American, European and Asian countries, etc.
There are different complete catalogues of the products: STD series: FR, HER, UF, SF, SKY, DB3, BRIDGE, H. V., TVS and so on. Also various package of diodes, small and medium size power transistor are available here. All products are accord with the Euro RoHS and ISO9002 standard. With the rapid development of technology in recent years, the company developed more SMA, SMB, SMC, SOD-323, SOD-123 series of diodes, and SOD-2, SOD-89 series of transistors to meet more customers' needs.
The motto of our company: Best quality and perfect service is guided by enterprise, continuing to improve ourselves in order to provide better service for customers.
