Product Specifications
| Prod Model: |
solarix PRS 1010 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Current: |
10A |
| Voltage: |
12V/24V |
Product Description
Fangpusun Solarix PRS
PRS 1010
The simplicity and high performance of the Fangpusun SOLARIX PRS solar charge controller make it particularly appealing. At the same time, it offers a modern design and a convenient display, all at an extremely attractive price.
Several LEDs in various colours emulate a tank display, which gives information on the battery's state of charge. Here, Fangpusun's latest algorithms are employed, resulting in optimal battery maintenance. The Solarix PRS charge controllers are equipped with an electronic fuse, thus making optimal protection possible. They operate on the serial principle, and separate the solar module from the battery in order to protect it against overcharging.
For larger projects, the charge controllers can also be equipped with special functions: E. G. With night light function and selectable charging plateau and deep-discharge protection voltages.
Product features
Series controller
Voltage and current regulation
Automatic detection of voltage
PWM control
Multistage charging technology
Current compensated load disconnection
Automatic load reconnection
Temperature compensation
Common positive grounding or negative grounding on one terminal
Integrated self test
Monthly maintenance charge
Electronic protection functions
Over charge protection
Deep discharge protection
Reverse polarity protection of load, module and battery
Automatic electronic fuse
Short circuit protection at module input
Overvoltage protection at module input
Open circuit protection without battery
Reverse current protection at night
Over temperature and overload protection
Battery overvoltage shutdown
Displays
Multifunction LED display
Multi-coloured LED
5lLEDs show operating states for operation, state of charge, fault messages
Options
Night light function pre-set in the factory or adjustable via Fangpusun PA RC100
Parameterisation of function values via PA RC100
Certificates
Compliant with European Standards (CE)
RoHS compliant
Made in China
We are professional manufacture for the Solar Charge Controller and DC to AC Inverter.
We are new and young company, but our products are sale to all of the world and very popular in Mali, South Africa, Nigeria, USA, Turkey, New Zealand, Germany, France etc.
We also develop the new items constantly according to the market requirenment.
Welcome to contact us to learn more.
