Product Specifications
| Prod Model: |
QT8-15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Blue |
| Weight: |
12t |
| Power: |
29.5kw |
| Body Of Material: |
Steel |
| Control: |
PLC |
| Automatic: |
Fully Automatic |
| Method: |
Hydraulic Pressure |
| Processing: |
Brick Production Line |
| Product: |
Brick |
| Brick Raw Material: |
Concrete |
| Certification: |
ISO9001: 2000, CE |
| Type: |
Concrete Iron Strengthen Machinery |
Product Description
QT8-15 is a multi-purpose machine. It can manufacture wall bricks, heat-insulating bricks, grass pavers, square pavers, slop protection pavers, road shoulder pavers, curbs, etc by simply changing the mould. When pressured, transform the excessive oil into vibration force. Computers control all directional vibration, frequency conversion, braking and cancellation of vibration energy consumption. Low frequency feeding, high frequency vibration and template suppressing vibration make the concrete fully liquefied and exhausted within two to three seconds. With the use of new technology, QT6-15 can produce 0.45 m2 blocks, 15PCS perforated bricks within 15 seconds, and QT8-15 model can produce 0.56 m2 blocks, 20PCS perforated bricks within 15s, notably raising working efficiency.
The model is designed with a device separating material storage and material distribution. Storage is photo-electrically controlled and material s is distributed as needed. Storage hopper is separated from vibration source to avoid premature liquefaction of some concrete due to the effect of aftershock Special arch device ensures rapid and even distribution of materials, a swinging distribution device is fixed in the hopper and the materials are evenly sent to the mould box.
The imported electric appliances, hydraulic elements and specially made oil box cooling system ensure fault-free operation of both controlling and hydraulic systems
Use human-computer interface and Chinese menu. The parameter is adjustable any time in accordance with the change of products and materials.
item | Unit of measurement | QT8-15 |
| Wall body brick block | Standard building block(pcs/mould) | 8 |
| Muti-pore brick(pcs/mould) | 20 |
| 95 standard brick(pcs/mould) | 40 |
| Pallet size | mm | 1100*680 |
| Double shifts annual yield | M3 | 120000 |
| Power | kw | 38 |
| Weight | t | 12 |
Nantong Hengda Non-Burned Machinery Engineering Co., Ltd. is a council member unit of China Brick & Tile Association and also the designated enterprise by the state of brick & tile machinery. We have passed ISO9001 (2000 version) International Quality Certification. Our products were awarded as "Chinese Brick & Tile Famous Excellent Products" by the Brick & Tile Industry Association of China.
Nantong Hengda Company has a good capability within development and innovation. Our company is a famous enterprise that produces vacuum squeeze machines and brick& tile machinery. We have enhanced our production capacity of vacuum extruders to ten primary machines and more than thirty secondary machines. The quality of the products is under the insurance of PICC, and it enjoys a high fame in the construction materials industry.
With more than forty years' development, Nantong Hengda Company boasts many senior technicians, advanced equipment, a precise quality testing system and a wholesome marketing and service network. Our products have a good market at home and abroad because of excellent quality, and they are sold successively in Europe, Southeast Asia, Africa and Arabia, highly trusted and applauded by consumers.
Nantong Hengda Company is situated at the scenic, voluminous stuff yields place, which is adjacent to Shanghai, Nanjing, Hu-ning, Ning-Tong Expressway, with Xin-Chang, Ning-Qi railway coming cross from north to south, enjoying convenient access.
Nantong Hengda Company has continually inventing & perfecting, and has earned further new development since our establishment. We are looking forward to making progress and sharing resources and civilization of technology together with our clients.
Our company president, Mr. Cui Hengquan, together with all the staff members, extends warmest welcome to domestic and foreign friends to our company for visiting and cooperating.
