Three in One Washing Filling Capping Machine

Product Specifications

Prod Model:	CGF18-18-6
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Three in One Washing Filling Capping Machine
Touch Screen And PLC:	Siemens
Bottle Size:	200ml-2000ml
Certificate:	CE, ISO, SGS
Power:	5.5kw
Weight:	2500kgs
Speed:	8000 Bottles Per Hour@500ml
Automatic Grade:	Automatic
Structure:	Rotary
Feed Cylinder Structure:	Multi-Room Feeding
Material Type:	Liquid
Filling Valve Head:	Multi-Head
Packaging Container Lifting Structure:	Chute Pneumatic Combination Lifting
Filling Principle:	Vacuum
Packaging Type:	Bottle
Packaging Material:	Film
Type:	Juice, Water
Dosing Device:	PLC

Product Description

Three in one washing filling capping machine


Main components of Three in one washing filling capping machine:
1) driving system;
2) bottle-loading system;
3) bottle-rinsing system;
4) handing-over system between rinsing and filling;
5) filling system;
6) handing-over system between filling and capping;
7) capping system;
8) cap-unscrambling system;
9) bottle-unloading system;
10) frame;
11) electrical system.



Technology parameter of Three in one washing filling capping machine:
1) model: CGF18-18-6
2) name: Rinsing, filling & capping machine
3) rinsing heads: 18
Filling heads: 18
Capping heads: 6
4) capacity: 5000bottle per hour (for 500ml bottle)
5) dimension: 4500mm (length)*2050mm (width)* 2200mm (height)
6) suitable bottle: Pet (sample provided by customer)
Diameter range: φ 50mm_φ 115mm
Height range: 160mm_320mm
7) suitable cap: Plastic anti-theft
8) frequency converter: Mitsubishi
9) main motor: 5.5kw
10) rinsing water pressure: 0.06 mpa < P ≤ 0.2 mpa
11) weight: 5000kgs



Rinser
Three in one washing filling capping machine
Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180° Along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.
Rinsing machine adopts JST Machinery original overturn and double-opened bottle clip. Bottle clip lock the bottleneck, the material of bottle clip is SUS304, which is hygienic and durable.
Bottle clip equipped with efficient spray on nozzle. The extrusive droplet with 15° Angleensures to wash all side of the bottle, and can save the water.

Filler
Three in one washing filling capping machine
Filling machinery design of filling structure is reasonable and hygiene dead angle, the run of equipment is stable, it can control the material from the bottleneck, the control accuracy is within ± 2mm (subject to bottle design). The filling valve material is SUS304. The filling system has liquid level automatic control. Filling valve lift is controlled by the valve elevator, after filling valve contact the bottleneck, it starts to fill. Bottle is conveying by the wheel in the filling part.

Capper
Three in one washing filling capping machine
Screw capping machine is most precision part in the 3-1 machine, it has a big influence to the goods stability and defective rate. Our screw capping has following feature.
JST iMachinery mport of advanced technology of screw capping, improve the stability and reliability of the screw capping machine. The magnetic torque is used for screw capping. Thepower of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.



Our service:
We will send one professional engineer to install the whole line for you, but you should pay him USD 60 / DAY as salary, also include his return tickets, room, food and visa fee.
Machine guarantee time: 12 months



How to get your suitable machine or production line?
Enquiry: Contact us by email, phone call, fax, Instant Messenger and let us know your enquiry.
Discussion: Specify the items you desire, confirm specification
Quotation: Prices offered and accepted.
Place order as per contract or discussion.
Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
Payment settled.
Order completed under our arrangement.
Goods shipped as per contracted term.
Goods arrive at local port or warehouse, depending on contracted term.

Any question about this machine, contact with us please, sincere service for you and welcome to JST Katherine.
