Product Specifications
| Prod Model: |
TNS-DW02 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Material Testing Machine |
| Weight: |
100-500Kg |
| Power Source: |
AC220V |
Product Description
TNS-DW Micro-computer controlled Torsion Testing machine This testing machine uses Computer-controlled AC servo system and is loaded through the active clamping
Head driven by the AC servo motor and cycloidal pinwheel redution motor. The torque and torsion angle are measured with high-precision torque transducer and photoelectric encoder. Computer will dynamically display the test torsion curve, loading speed, peak value, and so on. It is mainly used for the torsion test of metal and non-metal materials, as well as the torsion test for parts and components. It's an essential instrument to measure torsion properties of materials for mechanics laboratories of aviation industry, construction industry, scientific research dept., universities or industrial enterprises.
|
Specification |
TNS-DW02 |
|
Max Test Torque(N. m) |
200 |
|
Relative error of torque indications |
≤ ± 1% |
|
Torsion angle range |
0.01° ~ 9999.99° |
|
Relative error of torsion angle |
≤ ± 1% |
|
Resolution of torsion angle |
0.01° |
|
Resolution of torsion angle ( little angle measuring) |
0.002° |
|
Distance between two clamping heads(mm) |
600 |
|
Diameter of the specimen(mm) |
φ 8 ~φ 32 |
|
Torsion velocity |
0.18° ~ 720° /min |
|
Accuarcy of velocity |
better than ± 1% |
|
Directions |
two directions |
|
Power |
AC, 220V ± 10%, 50 Hz, Single phase |
|
Overload protection |
Provided |
|
Servo closed-loop |
Provided |
|
Dimension of package (mm) |
1800× 850× 1250 600kgs |
|
|
910× 650× 1280 50kgs |
TIME Group Inc. was established in 1984 is a leading manufacturer of Material Testing Machines in China. TIME Group Inc. has over 2, 800 dedicated, highly skilled employees in facilities located in China. From engineering, service, training, to front-line support, our commitment to customer satisfaction is the driving force behind everything we do. In 1995, we achieved the ISO 9001 certificate, and we have got many other certificates, such as CE. We are not only famous in China, but also have been exporting into more than 35 oversea countries and area.
JINAN SHIJIN GROUP was established in 1952, is the leading company in testing machine industry, honored as the excellent HI-TECH company in China. In August, 2003, TIME GROUP INC. Merged SHIJIN GROUP, this is a landmark in China testing machine industry.
We invested 180 million RMB to build a new factory of TIME SHIJIN GROUP in the Jinan economy & technology development district in 2010, and it occupies 102 Mu, with building area 46800 sq. M. It consists of 10 production lines: Foundry, Heat Treatment, Painting, Big Parts, Accessories, Bearings, Electric, Oil Sources, Load Frame, Installation & Calibration, Diversified Big Digital Controlled Processing Centers and 131 units of special machine tool equipments. The advantages of our new factory are not only the biggest production capacity in the Testing Machine industry of China, but also with the most modern technology.
Our main products include:
--Servo Hydraulic Universal Testing Machine
--Hydraulic Compression Testing Machine
--Electronic Universal Testing Machine
--Pendulum Impact Testing Machine
--Torsion Testing Machine
--Fatigue Testing Machine
--Friction & Wear Testing Machine
--Hardness Tester
--Spring Testing Machine
--Metallographic
