Vulcanization Conveyor Belt Machine Vulcanizing Press Machine

Vulcanization Conveyor Belt Machine Vulcanizing Press Machine
Price: US $ 1000-30000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,D/P,Paypal,Money Gram

Product Specifications

Prod Model: XLB
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Temperature: Adjustment
Heating Way: Electric/Oil/Steam

Product Description


Specifications
1.easy for installation and operation.
2.suitable for tiles ,gaskets ,conveyor belts
3.automatic and manual work style
vulcanization conveyor belt machine vulcanizing press machine

 features:

1.hot press machine is mainly used for vulcanizing all kinds of rubber & plastic products,which generally adopts column type with many features of compact structure, beautiful appearance, large pressure and so on.
2.It can be heated by electric,oil or steam,we can design and manufacture according to customers' actual requirement.
3.The electric system adopt PLC programming control , which is easy to be operated.
4.rubber hot press contains upper separator, base, Oil cylinder, plunger, activities, platform,
hot plate, the combination of pump.

technique parameter:



Type

XLB-DQ1200×1200×2

XLB-DQ1300×2000×1

XLB-Q1200×2500×1

XLB-Q1500×2000×1

XLB-Q1400×5700×1

Total pressure(MN)

315t

560t

750t

1000t

2800t

Platen size(mm)

1200×1200

1300×2000

1200×2500

1500×2500

1400×5700

Daylight (mm)

200

400

400

400

400

No of Daylights

2

1

1

1

1

Piston stroke(mm)

400

400

400

400

400

Plate Unit Area pressure(Kg/cm2)

22

21.5

25

33.5

35

Main motor power(KW)

3

8

9.5

11

43.5

Overall dimension(L×W×H) (mm)

1685×1320×2450

2000×1860×2500

2560×1700×2780

2810×1550×3325

2400×5800×3600

Weight(kg)

9500

17000

20000

24000

110000


The company owns powerful technical strength, advanced technics, the best design and strict quality guarantee system, which owns a high repution in China rubber machinery industry.

The main products are plate vulcanizing press, open rubber mixing mill, banbury intensive kneader, extruder, rubber and reclaimed rubber machinery, within the (outside) tires complete set of machinery.The products have been sold to more than 20 provinces and cities in China and have been exported to more than 10 countries and areas.All of the products are designed visually by three-dimension CAD design, quickly built module, limited element analysis, analogue action and interfering inspection.The combination of three-dimension CAD system and internet guarantees the synchronization with internatinal advanced technology.The combination of three-dimension CAD and CNC numeral process center realizes the transit from traditional manufacture to modern three-dimension manufacture.At the same time, the company keeps good contact with several universities and research institutes.

The company takes"To live by quality, To develop by reputation, To innovate by science and technology, To keep improving all the time"as managing ideas, and insists on the principle of "Quality is the first, Reputation is the?First, Client is the first" that will provide you the best service.
