Product Specifications
| Prod Model: |
XLB-1200*1200*1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Total Pressure(Mn): |
3.15 |
| Daylight(mm): |
300 |
| Daylight No.: |
1 |
| Unit Press: |
2.19 |
| Piston Stroke(mm): |
300 |
| Heating Method: |
Electric/Steaming |
| Type: |
General Rubber Machinery |
| Type Of General Rubber Machinery: |
Rubber Vulcanizing Machine |
| Type Of Tire Machinery: |
Rubber Vulcanizing Machine |
| Weight: |
<50 Tons |
Product Description
Vulcanizing Press, Vulcanizing Press Equipment XLB-1200*1200*1
This machine applies to sulfurizing various kinds of rubber and plastic model products as well as non-model products. The machine is in frame structure with below pressing form(upwards). Under the working hydraulic pressure, the embolism ascends to make hot plate close for getting pressure, while the embolism sescends( namely not plate turning on) by deadweight of hot plate, platform and embolish to drive working fluid to fuel reserve tank to achieve the aim of descending( namely turning on).
Made of nodular cast iron, the oil cylinder of machine is improved in compressive strength and wear resistance. Seal ring made of oil-proof rubber is placed in ou cylinder to have sealing effect in working process of this machine.
Combined oil pump, power source of the machine, provides working fluid with certain pressure. Working fluid enters into oil cylinder by control valve to make control handle on control valve turn to different places, and then embolism is able to ascend or descend.
Adopting tubular electric-heating component to heat uo, the machine can reduce air pollution to keep workshop clean without bolier.
The machine is beautiful in shape, convenient in control, safe as well.
Notes:
We can design and manufacture all kinds of non-standard rubber machininery according to the requirement of the custonmers.
| Type | XLB-DQ1200× 1200× 2 | XLB-DQ1300× 2000× 1 | XLB-Q1200× 2500× 1 | XLB-Q1500× 2000× 1 | XLB-Q2000× 3000× 1 | XLB-Q1400× 5700× 1 |
| Total pressure(MN) | 315t | 560t | 750t | 1000t | 1800t | 2800t |
| Platen size(mm) | 1200× 1200 | 1300× 2000 | 1200× 2500 | 1500× 2500 | 2000× 3000 | 1400× 5700 |
| Daylight (mm) | 200 | 400 | 400 | 400 | 400 | 400 |
| No of Daylights | 2 | 1 | 1 | 1 | 1 | 1 |
| Piston stroke(mm) | 400 | 400 | 400 | 400 | 400 | 400 |
| Plate Unit Area pressure(kg/cm2) | 22 | 21.5 | 25 | 33.5 | 30 | 35 |
| Main motor power(kw) | 3 | 8 | 9.5 | 11 | 26 | 43.5 |
| Overall dimension(L× W× H) (mm) | 1685× 1320× 2450 | 2000× 1860× 2500 | 2560× 1700× 2780 | 2810× 1550× 3325 | 2900× 3200× 2860 | 2400× 5800× 3600 |
| Weight(kg) | 9500 | 17000 | 20000 | 24000 | 66000 | 110000 |
Qingdao Shun Cheong Machinery Co., Ltd. (Original China Qingdao first Rubber Machinery Factory) was founded in 1968, which is a professional manufacturer in rubber machine field of China with high-tech technology. We have ISO9001: 2008, CE1282 and SGS certification. Our customers spread all over the world, such as the United States, Germany, Brazil, Singapore, Malaysia, India, Russia etc. Our company's major customers including: Michelin, Bridgestone Americas Tire Operations, LLC, Kumho, Cheng Shin Rubber Industry, United States Goodyear Tire & Rubber Company etc.
Reduce the production cost and supply high efficiency rubber machines are the target aim of our service. Our company is near from Qingdao steel factory and Qianwan port, which is largely lowering the logistics cost; Germany and United States' core talents and experienced engineers and outstanding technical teams have been introduced, constantly improving the R&D capability, with the advanced fabricating equipment to develop the world excellent rubber machine, satisfying the clients high requirements.
In order to supply better service for our customers, we also provide the conveyor belt production line, waste tire processing line, tire and other rubber products' producing on- site for customers to visit and consult.
1. Our company machines must pass inspection of 3-7 hours of load test operating before they leave the factory, thus saving customers' time and expense of equipment commissioning.
2. We provide one year's guarantee and once the equipment damage during this time we supply free of charge. In order to save maintenance time and reduce the production cost of the guests, you can contact our DCRC by email, MSN or Skype etc., and we will send professional technical personnel with English translation to you to solve equipment problems.
3. Our company establishes "CUSTOMER FILE" for sold equipment in the form of return visits regularly; Including equipment's maintenance, troubleshooting and customer feedback.
4. Complete after-sales service
