Wireless GSM GPRS Modem with RS232/RS485 I/O, Analog Input Output H20series

Name: Wireless GSM GPRS Modem with RS232/RS485 I/O, Analog Input Output H20series
Brand: china-manufacturer-directory.com
SKU: 716526865
Availability: InStock
Rating: 4.7 (145 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,EXW,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

H20series wireless GSM GPRS Modem with RS232/RS485 I/O, Analog Input Output

H20series Wireless GPRS GSM Modem RS232/RS485 I/O Designed with industrial grade, with TCP/IP stack, supports transparent data transmission, AT COM mand, RS232/485, remote configuration and control, with embedded Operation System, such as LINUX and WINDOWS OS, can be used as a modem for sending SMS, always online function makes data communication in real-time, etc. It has been used for data communication/acquisition, remote control and minotring, M2M appliation, etc.

Details

Wireless Specification

1. EGSM900/GSM1800
2. GPRS multi-slot class 10
3. Compliant to GSM phase 2/2+
4. Support SMS and data function

Hardware System

1. High-powered MCU, 100M
2. Interface:
RS232/RS485 serial port, rates: 110~230400bits/s
Indicator lights: "Power", "ACT", "Online"
Antenna interface: Standard SMA female interface, 50 ohm
SIM/UIM interface: Standard user card interface
Power interface: Standard 3-PIN power jack
3. Power supply:
Standard power supply: DC 12V/0.5A
Power range: DC 5~35V
4. Wireless module:
High-powered industrial GPRS module
5. Size:
Outline dimension: 102.8X73.5X24.6mm
6. Weight: 450 g
7. Others:
Operation temperature: -25~+65C
Storage temperature: -40~+85C
Humidity: 95% (unfreezing)

Software function

1. Design with standard TCP/IP protocol stack
2. Adopt smart online keeping technology to make sure that IP MODEM is always online
3. Support RSA and RC4 encryption arithmetic
4. Support APN
5. Support transparent data transfer and protocol conversion. Support multi work modes

6. Support dynamic domain name(DDNS) and IP access to data center
7. Support double data centers, one main and another backup
8. Support multi data centers, It can support 5 data centers at the same time.
9. Support multi online trigger ways, including SMS, audio and data. Support link Disconnection when timeout
10. Support SMS backup and emergency report

11. Support hardware and software WDT
12. Reporting the status of data transfer
13. Standard AT command interface
14. Support common MODEM function
15. Support telnet function

16. Support remote configure and control
17. Easy to upgrade firmware
18. Support multi OS, such as WINDOWS, LINUX, SCO UNIX etc.

Prod Model:	H20series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wan Port:	1
LAN Port:	1
Serial Port:	RS232/RS485
CPU:	Mips2
Use:	Power, Water, Gas, Metering, PLC, Sensor
Band:	850/900/1800/1900
Protocol:	TCP/IP UDP, HTTP, FTP
Weight:	450g
Housing:	Iron, Providing IP30 Protection
Dimensions:	102.8X73.5X24.6mm
Type:	External
Interface Type:	RS-232
