| Price: | US $ 1500/Piece |
|---|---|
| Trade Terms: | FOB,CFR,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union,Paypal |
| Prod Model: | D30 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: | 42" 6-Points Multi-Touch Screen All in 1 Digital S |
| Product Model: | Zktek/D30/42"/Rk3066/1gram/4gflash/Nogtv/Android4. |
| Outline Size: | 673X1221X60mm(Without The Installation Kits) |
| Net Weight: | 30kg |
| Display Monitor: | 42 Inches(16:9) Physical Resolution: 1920 X 1080 |
| Touchscreen: | Touch Method: 6-Points Infrared Touch; Touch Metho |
| Player: | Rockchip Arm Cortex A9 1.5 GHz(Max Upto 1.6GHz), G |
| OS: | Android 4.2.2, Can Be Upgrade to Windos 7/Linux |
| Operation Temperature: | 0c~40c |
| Storage Temperature: | -20c~60 C, Optional in 5c~35c |
| Certification: | CE |
| Queue System Type: | Queuing |
| Data Collector Type: | Industrial Data Acquisition |
| Data Collector Signal Transmission: | Wireless |
| Data Collector Operating System: | Android |
| Type: | Touchscreen Digit Signage |
| Currency Detector Type: | None |
| Currency Detector Principle: | None |
| Queue System Usage: | None |
| Queue System Display Function: | None |
| Product parameters | |
| Product Name | 42" 6-points multi-touch screen all in 1 digital signage |
| Product Model | ZKTEK/D30/42"/RK3066/1GRAM/4GFLASH/NOGTV/Android4.22/WIFI/Remote Control/Audio |
| Outline size | 673X1221X60mm(without the installation kits) |
| Net Weight | 30KG |
| Display monitor | 42 inches(16:9) physical resolution: 1920 x 1080 |
| Touchscreen | Touch method: 6-points infrared touch; touch methods: finger(gloved or not gloved or any optical obstacles |
| Player | Rockchip ARM Cortex A9 1.5 GHz(max upto 1.6GHz), GPU quad-core ARM Mali-400 MP, HYNIX/SAMSUNG DDR3 1Gbyte, HYNIX/SAMSUNG NAND FLASH 4GB(extensible TF/USB)(RAM and FLASH both can be upgraded) |
| OS | Android 4.2.2, can be upgrade to WINDOS 7/Linux |
| Ads software(application software) | Network GTV digit signage broadcasting and management system(also call GTV): adopt the "B/S" architecture, GTV digit signage system can broadcasting and managing: templates of the ads, program timing, program cycle broadcasting, display by list, inter-cut in emergency, Preset temporary content display etc. Support MD5 anti-intercept bi-way encryption, multilevel authorization; group terminal management, real-time monitor, remote control, power ON/OFF timing, multi-time partial download, flow control; authorization control, log and statics etc functions. With optional local C/S architecture for easy integration and management. |
| Audio system | Audio type: internal 2.0 mini multi-media loudspeakers, max rating:4-8 Ohm/2-10W x 2/Stereo |
| Main hardware specifications | |
| Touchscreen | 6 points Infra-red touchscreen |
| CPU | RK306 dual-core Cortex-A9 quad-core GPU Mail-400@ 533MHz FSB: 1.6 GHz(Can upgrade to Quad-core Rockchip RK3188/1.8G) |
| GPU | Quad-core ARM Mali-400 MP |
| FSB | 1.5GHz(Max upto 1.6GHz) |
| RAM | DDR3 1Gbyte,Brand:HYNIX/SAMSUNG |
| Storage | On-board NAND FLASH 4Gbyte, Brand: HYNIX/SAMSUNG |
| Extensible storage | TF/USB |
| Decode resolution | Max upto 1080P |
| Main Functions | |
| OS | Android 4.2.2 Can use the touchscreen and mouse to operate Can use WIFI to connect the Ethernet Can download and use the bank Apps(need SIM and 3G module) Can download and use original Android applications: i.e. Fruit Ninja, Angry Bird, Flappy Bird etc Can use all kinds of application develop for Android |
| FHD display | Auto playing on boot; display the multi-media content as programmed; display the preset screen template including: 1) Inter cut 2) Display on preset time 3) Display in cycle 4) Preset temporary content display |
| Network support | Suport 10/100M Ethernet Support WIFI(150Mbps) Can extend 3G module |
| Picture extrude | Picture extrude on the display area and full screen, the max picture resolution is 1080p. |
| Remote control over network | Support remote command parse and handling: message inter-cut, reset, hibernate, resume, power-OFF, power ON/OFF timing, set volume of the audio, application software update remotely, set the download speed threshold for the terminal. |
| Multi-media support | |
| Video Decoder | Real time video decoder, support MPEG-1, MPEG-2, MPEG-4,H.263, H.264, AVS, VC-1,RV, VP6/VP8, Sorenson Spark, MVC |
| Resolution of decoder | Support max upto 1080P@60fps |
| Video encoder | H.264,MVC, VP8 |
| Encoder resolution | Max upto 1080P@30fps |
| Picture format | Support JPG, JPEG, BMP, PNG, GIF |
| Text format | TXT(doc) |
| Video display | Support MPEG1, MPEG2, MPEG4, H.264, WMV, MKV, TS, flv |
| Audio play | Support MP3 |
| Basic interface | |
| USB | 1xUSB HOST |
| VGA video input | VGAx1 |
| HDMI video input | HDMI x 1 |
| 3G module interface | 1x PCIE, 1x USB |
| Power input | D-sub 220VAC power socket |
| Ethernet input | RJ45 LAN interface |
| Internal expansion support | 1x serial port 1x SPI port 1x Camera input 1x USB touchscreen port |
| Add-on functions | |
| RTC | Support |
| Power-ON/OFF timer | Support |
| System update | The application software can update through the following methods: 1) Network update mode; 2) USB download mode; |
| Electronic parameters | |
| Power input | 220VAC,1A |
| Standby power consumption | <=30W |
| Working Environment | |
| Operation temperature | 0 C~40 C |
| Operation humidity | RH, 10%~90%,NC |
| Storage temperature | -20 C~60 C, optional in 5 C~35 C |
