Prod Model: | FY3316B |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Model | FY-FY3316B | |
Print head | XAAR128,XAAR128/360 | |
Number of Print head | 4,8,12,16 Heads | |
Maximum Print Width | 3200mm | |
Output (m²/h) | Print mode | Standard Output (m²/h) |
240x540 3 pass | 70 | |
240x720 4 pass | 45 | |
240x540 6 pass | 33 | |
360x540 6 pass | 28 | |
720x720 8 pass | 16 | |
Ink | Type : | Solvent Ink / ECO-Solvent Ink |
Color : | 4 Colors( C , M , Y , K , ) | |
Capacity : | 1L or 5L per Main Tank of Each Color | |
Ink Supply System : | Low Ink Detector, Auto or Manual Ink Supply System | |
Media | Width : | 3300mm |
Type : | Vinyl, Flex, Polyester, Back-lit Film, Window Film etc. | |
Auto Media Feeding System | Equipped (Max. Media Weight 80kg ) | |
Auto Cleaning System | Positive Pressure Cleaning Anti-clogged Flash Function & Capping System | |
Pre-heating & Drying System | Equipped | |
Clamp | Equipped | |
Print Interface | Optical Fiber | |
Print head Height | 2 to 6 mm Above Media Adjustable |
