Outdoor High Voltage 3phase Permanent Magnet Vacuum Circuit Breaker

Outdoor High Voltage 3phase Permanent Magnet Vacuum Circuit Breaker
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: T/T,D/P

Product Description

High voltage Vacuum Circuit Breaker Details listed as belows

Adopt solid insulation structure, use of advanced solid epoxy sealing technology, the first time, the vacuum interrupter. A leading electrical circuit. Insulation and other support to become an integrated combination of solid seal pole. Successfully from a fundamental solution of the vacuum breaker gas environment, tolerance issues, make it more broad. Integrated solid-pole closure of the fluent use of a self-ventilation technology, cleverly solved the structure of solid insulation caused by heat dissipation.

Environmental conditions:
1. Ambient temperature: Not higher than +40 ° C, not less than -40° C

2. Altitude: Not exceed 2000m.

3. Relative humidity: Daily average of not more than 95%, month average of not more than 90%.

Saturated vapor pressure daily average of not more than 2.2 × 103MPa, month average not more than 1.8 × 103MPa.

4. Earthquake intensity: Not more than eight.

5. No fire, explosion hazard, serious filthy, chemical corrosion, as well as places of intense vibration.
Prod Model: ZW43-12/M630-20
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Zw: 43-12
M630: 20
Arc-extinguishing Medium: Vacuum
Breaking Capacity: High Voltage Circuit Breakers
Poles Number: 4
Certification: CCC
Operation: Electric Type
Installation: Open Frame
Speed: High-Speed Circuit Breaker
Structure: Permanent
YTO Power equipment factory specializes in producing Power Source as a member of China Power Supply Society. Since being founded, we has been insisting on the theoretic guideline of "Science & Technology is the first productive force" and holding up brand strategy as the guide, relying on forward understanding about power supply technology, perfect craft and unwearied pursuing to quality, we can show top quality power supply products, and set up fine image in Chinese market and abroad market.

YTO has the modern workshops and advanced production devices, besides we always introduce technology positively, reform craft continuously, devote to researching and developing kinds of Automatic Voltage Regulator/Stabilizer (AVR/AVS), Contact Voltage Regulator(Variac), Oil-immersed Transformer, Dry-type Transformer and Isolation Transformer and etc. In addition, we try to find excellent administrators and technical talents, through years on working hard, we has been improved on the aspect of quality, power supply varieties, producing scale, management mode, so products manufactured by us have reached advanced technical level, they are not only popular with a great of customers in China, but also in foreign countries.

YTO Products have been approved by Quality Supervision & Inspection(QSI), Insured by PICC, and also have CE, CCC certificates. We insist on the policy of developing by quality on the time, and also have passed ISO9001: 2000 Quality Management System Certificate. Relying on rich economic strength, fine production engineering, innovating management mode, we can dare to meet kinds of challenges from China entering WTO that is helpful for establishing reinforced foundation of international business.

We are keeping our business principle for " Approaching the first-class management, Producing the first-class products, Providing the first-class service". All YTO staffs are working hard and constantly innovate. Honest YTO are welcome to all users to fighting a better tomorrow hand in hand.
