LED Solar Street Light
Light FixtureMaterialAluminum die casting & Toughened glass
Operating Temperature-40° C~75° C
LED Light SourceLED ChipBRIDGELUX / Cree (Top brand in U. S. A. )
Luminous flux5300 LM
Operating temperature-40° C~75° C
Current SourceDC 12V/24V
Lighting PoleHeight3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m
MaterialBAOSTEEL GROUP Q235/345/GR60
Surface TreatmentHot-dip galvanizing, Static spray,
Sizeφ 60-φ 200, δ 3-5m, vary according to models
Flange Plate300*300*16, vary according to models
ControllerRated voltage and current12V/10A or 24V/10A waterproof
Two times rainy day backup
&Protective FunctionTwo times of rainy day backup.
Good protection: Overcharging, discharging, voltage surge, reverse polarity, etc.
AccessoriesCable2.5 mm2, 15m
Battery Box200AH ABS battery box or metal box with hot-dip galvanizing spray treatment
Foundation KitDismountable foundation kit, saving in shipping
Solar Street Light Details
A GRADE high efficient solar panel
Mono: 18% convert efficiency
Poly: 17% convert efficiency
5 years warranty for solar panels
USA BRAND LED and Aluminum Section Bar Light Fixture
Long life time: 1W LED with 1 heat sink, fast heat dissipation makes it 100, 000 hours long life time
STRONGER POLE with 20 years life time
Larger diameter: Our pole is 10% larger in diameters
Thicker wall: We offer 0.25mm thicker pole than that of the market. For example, we offer 3mm thickness for 6m pole, while other, 2.5-2.75mm
Bigger foundation kits: For example, we offer M18-20*1000mm bolts for 6m light, while others, M16-18*800mm
Thicker zinc galvanization and painting: We offer 100 μ M zinc and coating than the standard 80 μ M
TWO TIMES rainy day backup waterproof controller
Rainy day backup: 2 times more rainy day backup, savings in battery
Combined LED driver and controller as one, easy to maintain
IP67: Ideal for high humidity and dust areas
Energy saving mode: THREE periods of power adjustment available
All metal shell: High strength and fast heat dissipation, giving long life time
BAODE guarantees the purchaser for the period of two (2) years that BAODE's new lighting systems will be free from defects in materials and workmanship. BAODE will, at its option, repair or replace any BAODE's system that is defective for a minimum of two (2) years after the date of purchase.
BAODE offers detailed instructions and videos for installation. Besides, BAODE can provide onsite installation training and technical assistance free of charge in initial period for large projects more than 100 poles because we has developed her experienced technical team.
Spare Parts Policy
BAODE provides 0.5% to 1% of spare parts for free based on the transaction amount.
|Light Fixture||Material||Aluminum die casting & Toughened glass|
|LED Light Source||LED Chip||BRIDGELUX / Cree (Top brand in U.S.A.)|
|Luminous flux||5300 LM|
|Current Source||DC 12V/24V|
|Lighting Pole||Height||3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m|
|Material||BAOSTEEL GROUP Q235/345/GR60|
|Surface Treatment||Hot-dip galvanizing, Static spray,|
|Size||φ60-φ200,δ3-5m, vary according to models|
|Flange Plate||300*300*16, vary according to models|
|Battery||Capacity||200AH (100AH*2pcs) |
|Controller||Rated voltage and current||12V/10A or 24V/10A waterproof |
|Two times rainy day backup|
|Two times of rainy day backup.|
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.
|Accessories||Cable||2.5 mm2, 15m|
|Battery Box||200AH ABS battery box or metal box with hot-dip galvanizing spray treatment|
|Foundation Kit||Dismountable foundation kit, saving in shipping|
BAODE will offer technical guidance and repair service for the whole life time of her products.
BAODE promises to respond with customer's questions within 24 working-hours.
Payment terms: 30% in advance and 70% before shipment.
Lead time: 2~3 weeks upon receipt of payment for 50 poles.
Shipping: Generally, solar lights are shipped by sea. Battery and pole are not available to ship by air.
Package: Individual package for each component of solar light. Wooden box for LED lamp and solar panel for LCL goods. 80 poles load a 40 HP container for 8M solar street lights and 60-3.5m solar garden lights in a 20 container.
You can find solutions for almost all outdoor lighting from us, like street lighting, square lighting, landscape lighting, traffic lighting and commercial lighting and so on.
Vertically Integrated Production System
You will enjoy high-quality product with cost-effective price from us because we manufacture most of the main components from LED source, light fixture, solar panel, pole and even painting powder to control the cost and quality.
15 Years Manufacturing Experience
Since 1998, we have started manufacturing street lighting. The 15 years' experiences have been a persuasive insurance for us to offer reliable products.
Large Factory with Complete Facility
We have 400 staffs with factory area 6000 m2. We also equipped with complete production and testing equipments, such as Steel Pole Rolling Machine, Spray Machine, Pressure Machine, Integrating Sphere, Lighting Simulating Machine and Weather-ability Testing Machines, etc . .
Our 60 experienced engineering team work with the PV institute of Shanghai FUDAN University , Shenzhen Foxconn to R&D outdoor lighting products. We have obtained over 20 national patents and built our own brand LUYOU.
Manufacturing main components to save cost. BAODE manufactures the solar panel, light fixture and pole to control the cost and quality.
Factory outlet. There's no middleman between the manufacturer BAODE and domestic and oversea buyers.
Jiangsu Baode Lighting Equipment Co. Ltd. is located in Songqiao industrial zone in the north of Yangzhou city, Jiangsu province, and enjoys highly convenient communications and smooth traffic access.
Under the leadership of Mr Baosheng Zhang, Baode has been advocating a corporate spirit of good faith, high efficiency and moving with the times. After over ten years of hard work it has grown into a big enterprise with registered capital up to 8, 038 million yuan, annual sales of over one hundred million yuan and covers an area of 40, 000 square meters. Baode has over 50 high level intellectuals, experts and technical staff and boasts over 120 sets of large and medium-sized equipment. It has set up long-term corporation with Shanghai Yaming, Nanjing Sanle, Shenzhen Gaolite and Wuxi Zhenfa in the transmission and distribution lines and solar panels. So far Baode has over ten patent technologies. The Jiaozi lamp series and solar powered lamps have been widely used in the industry.
In order to build up the brand name "Luyou" and keep the company growing, Baode stresses the concept of quality. Baode has established a full series of rules for labor management, production management and quality management, has formulated technological flows, quality criteria and rules of encouragement and discipline on the basis of different work positions and maintains real time control over the production process by means of a CCTV monitoring system. The Q. C. Department of the company maintains strict discipline in controlling product releases to ensure all the products delivered are 100% qualified to achieve zero returns. Based on goodwill, advanced technology, excellent product quality and reasonable prices we have won abroad market share and trust from our customers. Baode has been involved in national key projects many times. "Luyou" brand lamps have been used in Beijing, Shanghai, Tianjin, Qinghai's Ge'ermu airport, the sea-spanning bridge of Quanzhou in Fujian province and the seaside Bath site on Huludao island, in Liaoning province. The lamps have also experienced the test of severe cold, wind and snow in Harbin and Lhasa. At the same time Baode products have been sold in Europe, America, South-east Asia, MID-Asia, Australia and Africa and received high praise from overseas customers.
For many consecutive years, Baode has been appraised as a "faithful and trustworthy enterprise", "the enterprise with the top credit rating of AAA", "an excellent company in standard implementation" and "an outstanding enterprise in quality management". It has received accolades as a well-known brand of Yangzhou and of Jiangsu province and is recognized for the certification of its high-tech solar street light. It is also successfully certified with ISO9001: 2000, ISO14001: 2004, CCC, CQC and has been granted the permit for the use of high mast lamps at airports, issued by the CAAC. Baode has also been granted the "Permit for safety production" and the"Qualification of road lighting construction", "Certification of transformation of steel tubular structure products", "Radio communication towers and mast production certificate" and "Traffic lights certificate" among others.
Baode is ready to work with old and new customers in full sincerity to make the night of the world more colorful.
