Product Specifications
| Prod Model: |
XYL-UF-1.0T/H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Membrane Brand: |
Vnf |
| Controlling Head: |
by Man |
| Pump Brand: |
Nanfang |
| Piping: |
Upv-C |
| Stainless Steel Frame: |
by 304 |
| Power: |
0.55kw |
| U F4040: |
2piece |
| Pre-Treatment Tank: |
300*1650 |
Product Description
Hollow-Fiber Ultrafilter 1T/H
The filter is the dissymmetrical semi-permeable film made from polymer material with special process. The raw liquid flows inside or outside the film under the pressure. The polymer materials and colloid particles are prevented on the film surface and brough away by circulating raw liquid. Then the raw liquid becomes concentrated liquid, thus achieving the objectives of separation, concentration and purification.
Capacity List below:
UF-1.0T/H
UF-2.0T/H
UF-3.0T/H
UF-5.0T/H
UF-10.0T/H
Hollow fiber membrane Ultra filtration system water treatment equipment
Brief introduction:
Ultra-filtration is a pressure-driven membrane separation technology. Ultra-filtration membrane is the anisomerous semipermeable membrane made ofmacro molecule materias the separation method without phase transition for solution, and can remove particles whose molecule weight ranges 1, 500-100, 000 Dalton, and can effectively remove organic, bacterium, virus, colloid and non-ion suspended solid.
System flow process:
Raw Water Raw water pump sand filtercarbon filterwater softenersecurity filter
High-pressure pump UF system pure water tank
Feather:
Automatic controller, PLC controller
Low power consumption, can operate in normal temperature and low pressure
Automatic backwash and pressure protection system.
Small size, simple structure, beautiful surface, low investment.
The processing in only liquid transportation by pressure, so the flow chat is simple and easy to operate and maintain.
High desalination and recovery rate and the production water can meet the WHO drinking standard.
One year warranty and whole life service and we also supply technical support.
Application:
Drinking water
Clarifying and eliminating bacterial for mineral water
Concentration and refinement of milking
Separation and refinement of enzyme
Concentration and refinement of biologic products
Concentration and separation of fruit juice
Water treatment for medicine
Pre-treatment of large water treatment equipment
Terminal treatment of ultra-pure water for electronic industry
Pouring in water treatment for extremely low permeable wells in oil field
Treatment of industrial waste water and reclamation of usable water.
Zhangjiagang city XY-LONG machinery Co., Ltd is a professional manufactory located in zhangjiagang city jinfeng town, we have more than 10years experiences on beverage machinery.
We devote ourselves to the development, research and production of liquid food and beverage packing and filling industry machine in China, especially model QGF series barreled production line.
For beverage machine, our Main products including:
The capacity of 5000-- 40000 BPH for hot filling, MID-temp filling, aseptic cold filling lines.
The capacity of 5000-- 40000 BPH for mineral water and purified water producing line.
The capacity of 5000 -- 36000 BPH for carbonated beverage producing line.
The capacity of 300 -- 2000 TBH, for 3 gallon, 5 gallon.
All kinds of water treatment equipment.
PET perform inject and blowing-stretching machine. Mould plastics machine
Turn-key projects
Flat and tube UHT device, and CIP system.
All the products are sold well in every province and city of the whole country and also exported to about thirty countries and areas with strong technical force, advanced equipment, scientific management system and perfect after-sales service.
Welcome to visit our company. Thank you!
