Product Specifications
Prod Model: |
XA-SS037 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wire Diameter: |
0.02-1.5mm |
Mesh: |
1-500 Mesh |
Width: |
0.5-2m |
Length: |
100ft Per Roll |
Grade: |
202,304,316 |
Certificate: |
ISO9001 |
Material: |
SUS304 |
Hole Shape: |
Square |
Application: |
Window Curtain |
Type: |
Stainless Steel Plain Wire Mesh |
Material Type: |
Stainless Steel Wire |
Weave Technique: |
Plain Weave |
Wire Mesh Width: |
1.2m |
Technique: |
Woven |
Nickels: |
8% |
Product Description
Size:
Standard roll width: 1m to 1.2m
Standard roll length of stainless steel wire mesh: 30m to 100''
Type 304 often refers to as 18Cr, 8 Ni, Type 304 is the basic stainless alloy mostly commonly utilized for wire cloth weaving. It withstands outdoor exposure without rusting and resists oxidation at an elevated temperature up to 1400 Degrees Fahrenheit. Type 304: Is very similar to Type304, the difference being the reduce carbon content for better weaving and secondary welding characteristics.
Type 316: Stabilized by the addition of 2% molybdenum, Type 316 has better resistance to pitting corrosion than the chromium-nickel stainless steels where brines, sulfur-bearing water or halogen salts, such as chlorides are present. Type 316L: Is very similare to type 316, the difference being the reduce carbon content for better wire cloth weaving and secondary welding characteristics.
Applications:
Stainless steel wire mesh made from choice wires are used for separation of solids and clear filtration of liquids, as in the cleaning of fuels, or hydraulic liquids, or in water treatment.
Mesh | Wire Dia. (MM) | Opening (MM) | Material (AISI) |
2meshx2mesh | 1.8 | 10.9 | 304 or316 |
3meshx3mesh | 1.5 | 6.96 | 304 or316 |
4meshx4mesh | 1.0 | 5.35 | 304 or316 |
7meshx7mesh | 1.00 | 2.63 | 304 or316 |
10meshx10mesh | 0.60 | 1.94 | 304 or316 |
12meshx12mesh | 0.50 | 1.62 | 304 or316 |
16meshx16mesh | 0.40 | 1.19 | 304 or316 |
16meshx16mesh | 0.35 | 1.24 | 304 or316 |
18meshx18mesh | 0.35 | 1.06 | 304 or316 |
20meshx20mesh | 0.40 | 0.87 | 304 or316 |
24meshx24mesh | 0.26 | 0.80 | 304 or316 |
30meshx30mesh | 0.30 | 0.55 | 304 or316 |
35meshx35mesh | 0.17 | 0.56 | 304 or316 |
40meshx40mesh | 0.23 | 0.40 | 304 or316 |
50meshx50mesh | 0.20 | 0.31 | 304 or316 |
60meshx60mesh | 0.15 | 0.27 | 304 or316 |
70meshx70mesh | 0.12 | 0.24 | 304 or316 |
80meshx80mesh | 0.13 | 0.19 | 304 or316 |
90meshx90mesh | 0.12 | 0.16 | 304 or316 |
100meshx100mesh | 0.10 | 0.15 | 304 or316 |
120meshx120mesh | 0.09 | 0.12 | 304 or316 |
150meshx150mesh | 0.063 | 0.11 | 304 or316 |
180meshx180mesh | 0.053 | 0.09 | 304 or316 |
200meshx200mesh | 0.053 | 0.07 | 304 or316 |
250meshx250mesh | 0.040 | 0.063 | 316 |
Anping Xinao Metal Product Co., Ltd. is located in "The Capital of Wire Mesh" and "Chinese Wire Mesh Industrial Base" - Anping. Our company is a leading wire mesh manufacturer, which integrates wire drawing, net weaving, screen deep-processing and sale. Our main products are metal wire, wire mesh fence, welded wire mesh, crimped wire cloth, gabion mesh, SNS flexible protection net, woven wire mesh and more, which are widely used in many fields including building, railway, chemical, aerospace, aquiculture and others, distributed to Europe, America, India, the Middle East, Hong Kong and other countries and regions.
Xinao has attained ISO9001: 2000 certification. Our products have been proved by a scrupulous test. At the same time, we strive to provide helpful and timely service and to supply the highest quality wire mesh at competitive prices. Besides, in the past several years, our company has insisted on introducing high-technology and new talents, and has cultivated efficient and young professionals. With advanced technique, strict management system, strong development, innovation strength, and the principle of "quality & credibility first", we have won new and old customers' trust and appreciation.
We are convinced that with our joint efforts, business between us will bring us mutual benefits. We sincerely hope we can establish business relationship with new and old customers at home and abroad on the basis of "friendly cooperation and mutual benefits". We welcome any unit to visit our company and negotiate to create a glorious future.
