Product Specifications
| Prod Model: |
ABT-100 |
| Markets: |
North America,South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Voltage: |
DC12-24V |
| Colour: |
Black |
| Case Material: |
PC |
| Size: |
171*82*77mm |
| Certification: |
CE,FCC,RoHS,IP55 |
| Response Speed: |
50~700msec |
| Type: |
Anti-Theft Alarm |
| Application: |
Outdoor |
| Signal Transmission: |
Wired Alarm |
| Working Mode: |
Active |
| Sensor Type: |
Infrared Alarm System |
| Usage: |
Wall |
| Working Principle: |
Active Infrared Beam |
Product Description
Features of 100m 2 beams motion sensors & cheap motion sensor:
1. When faced with fog or inclement weather, the detector sensitivity will increase automatically(AGC circuit)
2. Up and down optical lens can adjust the mechanical design, making adjustments more faster, convenient and accurate
3. Ten signal design, horizontal/vertical optical angle adjustment is convenient, easy to calibrate
4. Artificial Intelligence recognition technology, digital conversion and superior signal filtering
5. With high levels of anti-RFI/EMI capability
6. Unique design of the digital filter circuit
7. High-power transmitter, sensitivity surplus degree up to 90%
8. Anti-lightning circuit design
9. With rain cover design, C relay output
10. Adjustable of beam interdiction period, to make it more flexible and adaptable
11. Professional anti-jamming optical housing
12. High-power infrared receiver tube, low-power process technology
13. Anti-glare up to 50, 000 LUX, built-in automatic adjustment strong light filtering system
Our Advantage of 100m 2 beams motion sensors:
1. The same product, the lowest price.
2. The same price, the best quality.
3. The same quality, the fast delivery time.
To provide our customers with best 100m 2 beams motion sensors price and quality.
Company Introduction:
(1)Having our own factory which provides you the most competitive 100m 2 beams motion sensors price.
(2)CE, FCC, ROHS, IP55 for some products and ISO9001 certificate make you satisfied with quality when using our products.
(3)Professional team provide you the latest design and satisfying sevices.
Thanks for your time of viewing.
Please contact me freely to get more information for 100m 2 beams motion sensors price & cheap motion sensor (ABT-100).
|
Model: |
ABT-20 |
ABT-30 |
ABT-40 |
ABT-60 |
ABT-80 |
ABT-100 |
|
Outdoor alert distance: |
20m |
30m |
40m |
60m |
80m |
100m |
|
Indoor alert distance: |
60m |
90m |
120m |
180m |
240m |
300m |
|
Beam: |
2 |
|
Induction speed: |
50-700ms |
|
Alarm output : |
NC& NO contact rating: AV/DC 30V/0.5Amax |
|
Ganged Alarm: |
Yes |
|
Working voltage: |
DC12-24V |
|
Working current: |
40mA |
40mA |
55mA |
55mA |
65mA |
65mA |
|
Long-life mode: |
20mA |
20mA |
30mA |
30mA |
35mA |
35mA |
|
Humidity: |
5%-95% (RH) |
|
Tamper output: |
NC contact rating: AV/DC 24V/0.5Amax |
|
Horizontal angle adjustment: |
180° ± 90° |
|
Vertical angle adjustment: |
± 10° |
|
Case material: |
PC |
|
Dimensions: |
171*82*77mm |
|
PCS/CTN: |
20PCS/CARTON |
|
Packing dimensions: |
49.5*45.0*36.0cm |
