10mw Green Laser Wide Temperature Range (GLM-010D)

Name: 10mw Green Laser Wide Temperature Range (GLM-010D)
Brand: china-manufacturer-directory.com
SKU: 708026925
Availability: InStock
Rating: 4.6 (112 reviews)

Supplier:	Elite Optoelectronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	GLM-010D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wavelength:	532nm
Operate Temperature Range:	-10°c~50°c
Life Span:	> 5, 000hrs
Delivery Time:	10-20day Depending on The
Manufacturing Technology:	Optoelectronic Semiconductor
Material:	Element Semiconductor
Type:	P-type Semiconductor
Package:	Customized

Product Description

- 10mW output power
- CDRH CLASS: CLASS IIIb
- High quality and stability
- High Reliability>98%
- Wide Operating temperatur

(10mW Green Laser) GLM-010D

GLM-010D is a kind of wide temperature operating laser module. Its operating temperature range is
-10° C~50° C. This outstanding performance is specially designed for outdoor application such as laser surveying; Aiming and laser alignment. Internal photodiode is included for stabilizing output power. Compact design and low power consumption are both the advantage for OEM use.

Key Features: Application:
Wide Temperature Operating Surveying Equipment
Auto Power Control (APC) Laser Alignment and Positioning
High Reliability Laser Sight.

Parameter	Spec.	Test Conditions
Wavelength	532 nm	T_c = 25° C
Output Power	10mw	T_c = 25° C
Laser Modes	CW
Transverse mode	TEM₀₀
Output Aperture	< 1.5 mm	Factory fixed
Beam Size	< 10 mm	Factory fixed @ 15m
Divergence	< 0.6 mrad	T_c = 25 ± 3° C
Stability	> 70 %
Operating Current	< 300 mA	T_c = 25 ± 3° C
Operating Voltage	3 VDC
Operating Temp.	-10° C~50° C
Storage Temp.	- 20° C ~ 70° C
Optics	Glass Lens
CDRH Class	Class IIIb
MTTF	5000 Hrs.	T_c = 25 ± 3° C
Dimensions	12 x 40mm

Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.

Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.

Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.

Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
