CPU(GHz)1.86G
Core LogicIntel Atom D2550
System Memory (DDRIII)2G, or 4G
OS SupportWin XP, Win Vista, Win 7, WEPOS, Linux
Display
TFT LCD15"
Brightness250 CD/
Resolution1024X768
Touch Screenmapletouch 5wire resistive
Tiliting Angle(degree)15-90
Storage Device
HDD(GB) 2.5" SSD 32G, optional 320G, SSD 16G
I/O Ports
Serial(RS232)2 X RS-232 (Maximum extension 6*RS232)
USB4 USB-2.0
PS/21
LAN1*Realtek RTL8111DL 100/1000Mbps, can optional two LAN interface
VGA1*dB-15
Cash Drawer(RJ11)yes
LPT1*dB-25
AudioRealtek ALC892 Audio
Wirelee LAN optional
Expansion1*PCIex1, 1*Mini PCI-E Expansion slots
Others
ColorBlack, Silver
CertificationsCE, FCC, CCC, RoHS, CB
Weight (Kg)8
Optional Accessories
2ND DisplayYes
Customer DisplayVFD2X20, Cost extra $52
MSRTrack1+2+3 Cost extra $45
I ButtoniButton / Dallas Key Reader, KB I/F, I Key N/A
Wall Mount BracketYes, (option) VESA 75 mm
Main Board |
|
CPU(GHz) |
Intel Celeron 1037U 1.8Ghz Dual Cores CPU |
Chipset |
Intel NM70 Mobile Chipset |
Motherboard |
Industrial stable MP-1037U |
System Memory (DDRIII) |
2G (can update 4G) |
OS Support |
Win XP, Win Vista, Win 7, WEPOS, Linux(test version) |
Display |
|
TFT LCD |
15" |
Brightness |
250 cd/ m2 |
Contrast Ratio |
600:1 |
Color Resolution |
16.7M |
Resolution |
1024x768 |
Touch Screen |
mapletouch 5wire resistive (USB/RS232 Optional) |
Tiliting Angle(degree) |
15-90 |
Storage Device |
|
Hard disk(GB) |
2.5" SSD 32G(optional 320G,SSD 16G) |
Back Panel I/O Ports |
|
|
1*DC12V Power in connector |
|
4*USB 2.0 Ports |
|
1*HDMI Port |
|
1*VGA Port |
|
1*RJ45 LAN Port |
|
1*MIC-IN, 1*Line-out |
Work Environment |
|
Operating temperature/humidity |
-10~60 /20-85% |
Storage Temperature |
-30~80 |
Others |
|
Power input/output |
100-240VAC~50-60HZ 1.5A/ 12V 5A MAX (adaptor) |
housing material |
Aluminium alloy |
Installation mode |
Desktop,wall mounted |
Color |
Black (Optional White) |
Certifications |
CE, FCC, CCC, RoHS,CB |
Weight (Kg)/Dimension |
8kg/368*283*55mm |
Guangzhou yulian electronic technology Co., Ltd. is the mainly professional manufacturer in producing mapletouch POS terminals, industrial control systems and multifunction inquiry touch kiosks in China. We have been an innovative and creative force in the development and manufacturing of high quality, high performance systems since 2000. Now our products have obtained the certificates of ISO9001: 2000, CE, FCC, CCC, CB, ROSH and widely applied to many fields.
