Product Specifications
| Prod Model: |
HCB-L1201 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Numbe: |
Hcb-L1201 |
| LED Power: |
120W |
| Operating Voltage: |
10-30 DC |
| Waterproof Rate: |
IP 67 |
| Chip: |
5W High Intensity CREE LEDs |
| Color Temperature: |
6000k |
| Lens Material: |
PC |
| Opitonal Beam: |
Spot Bean (8degree), Flood Beam (120degree |
| Life Time: |
30000 Hours Above |
| Dimensions: |
39 Inch |
| Certification: |
CE, RoHS,Emark |
| Voltage: |
10-30V |
| Application: |
off-Road Vehicles |
Product Description
Led light bar
Our company produces the LED Work Light, LED Work Lamp, LED Light Bar, LED Bar, Light Bar, Offroad LED Light Bar, LED Bar Lighting, LED
Lighting Bar, LED Off Road Light Bar, is based on excellent design technology, excellent quality, and best service, to win the majority of customers praise and trust.
120W CREE LED work bar light for Truck SUV
Information:
. LED Power: 120W
. Raw Lumen:10800lm
. Operating Voltage: 10-30 DC
. Waterproof rate: IP 67
. 24pcs*5w high intensity CREE LEDS
. Color Temperature: 6000K
. Material:Diecast aluminum housing
. Lens material:PC
. Mounting Bracket: zinc alloy
. Beam pattern: spot Bean (8degree), flood beam (120degree)
. Dimensions: 39 inch
Advantages&Features:.
1Wide operating voltage range: it can apply to different types of trucks,cars,and other vehicles.
2)Adjustable brackets and mounted up-side down (180°),
the appearance of fine craft and easy to install brackets.
3)Different sizes to choose from installed in different locations.
4)Replace glue with the waterproof apron and screw ,easy to install and dismantle .
5)Long life: more than ordinary advanced LED light bulbs, more than 30000 hours life
6)Aluminum casing, shock-proof waterproof better.
7)Waterproof and anti-corrosion: it can in the rain or harsh environments.
Single row led light bar with with adjustable brackets and mounted up-side down (180°),please see below
Item No Power Lumens Size LED Chip
HCB-L301 30W 2700lm 10.5" 6pcs*5W
HCB-L601 60W 5400lm 20" 12pcs*5W
HCB-L901 90W 8100lm 29.5" 18pcs*5W
HCB-L1201 120W 10800lm 39" 24pcs*5W
Application:
1.Off-Road vehicles:4x4,ATV,SUV,UTV,truck,Fork lift,train,boat,bus,and tanks.
2.Engineering vehicles:Excavator,dozer,road roller,Bulldozer,crane and mining truck.
3.Specialized vehicles:Fire engine,Police car,rescue vehicle,communication vehicle,military command vehicle etc.
Why the Single row LED light bars are hot selling ?
a.High quality: It is made of CREE LED chips.
b.The brackets can be mounted up-side down (180 degree).
c.The spacing of the brackets is adjustable.
d.No Glue at all, easy to disassemble.
e.Totally waterproof (IP67)!
We regard quality as our life.So before delivery,we do so much process as below:
1---Material arrive at our factory,our QC staff check,after pass,enter warehouse waiting for application
2---Finished product need burn-in board checker.That means,light up for two-hour test,to confirm each one work and quality guarantee
3---After burn-in board checker,sink in water for watertight test
4---After watertight test,instrument test.Such as:Current,Voltage,Power testing.
5---And then delivery in the date requested.
Q:Are there any testing be done before shipment?
A:Each light has passed the resist shock testing, electrostatic protection testing,waterproof testing ,aging testing and low temperature testing.
Q:Can I buy some samples for test before I place an order?
A:Sure, samples will be offered as you requested.
Q:OEM service is accepted?
A:Yes, OEM service is available.And there will a MOQ requirement
Q:Why buy from us?
A:High quanlity,best service and price,positive attitude.Defective raw is Less than 0.3%.Reply ASAP during work time even off-work time.
Big discount can be 1%~ 10% for bulk order.
HCB-L1201 |
| Model Numbe: | HCB-L1201 |
| LED Power: | 120W |
| Raw Lumen: | 6800lm |
| Operating Voltage: | 10-30V DC |
|
|
|
| Waterproof rate: | IP 67 |
| Chip: | 24pcs*5w high intensity CREE LEDS |
| ptional Color:: | Black,White |
| Color Temperature: | 6000K |
| Material: | Diecast aluminum housing |
| Lens material: | PC |
| Mounting Bracket: | zinc alloy |
| Opitonal Beam: | spot Bean (8degree), flood beam (120degree) |
| Life time: | 30000 hours above |
| Dimensions: | 39inch |
