Product Specifications
| Prod Model: |
MJK-1530CS2-ATC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Table Area: |
1300*2500mm |
| Operating System: |
Syntec Control System |
| Driving System: |
Yaskawa Servo Motor and Driver |
| Inverter: |
Taiwan Delta |
| Spindle: |
Italy Hsd Spindle |
| X,Y Axis Transmission: |
X,Y Helical Rack and Pinion |
| Z Transmission: |
Ball Screw |
| Software: |
Ug,Master Cam,Art Cam,Visual Mill,Type 3 |
| Warranty: |
One Year |
| Spindle Layout: |
Vertical |
| Spindle Number: |
Single-Spindle |
| Feed Mode: |
Mechanical |
| Controlling Mode: |
CNC |
| Certification: |
SGS |
Product Description
MJK-1530CS2-ATC
1:Main configuration
Adopt world top class mechanical and electronic components,e.g.
Japanese rack and pinion
Taiwan Hiwin Linear rail and ball screw
Japanese reducer
French Schneider electrical components
Italian ATC spindle
Syntec Controller
Yaskawa Servo Motor and driver
Which guarantee stable performance and high quality.
2:Advantages
1:Function: Extremely heavy-duty CNCmachining center,suitable for routing,relief,drilling,cuting,edge chamfering,etc.
2:Construction:Whole machine table adopt high strength thick steel pipe welded.Whole working table cast by resinsand.The annealing and other heat treatment methods ensure that the whole structure is tested to the limit for sturdiness and reliability.
3:Precision:Excellent spare parts, sophisticated detection instrument,which make sure the machine with perfect location and working precision.
4:High-speed:High torque,high-energy,Y-axis dual motor drive,runs smoothly with high efficiency.
5:Table:Vacuum table using high-density (1.3-1.45g/cm) material with great suction strength, comfortably accommodating all sizes of work piece
6:Tool magazine:Two Carousel Tool Magazines,saving more processing time than traditional ones.
7:Controller: Syntec controller-enabling this product to accomplish multi-layer 3D job, cutting, engraving, milling.
8:Intelligent processing cross-border protection function can prevent the excessive processing caused by mechanical collision.
3. Technical parameter
| MJK-CS2Series | MJK-1325CS2 | MJK-1530CS2 | MJK-2040CS2 |
| Table area | 1300*2500mm | 1625*3150*250mm | 2100*4100*250mm |
| Travelling area | 1320*2540*250mm | 1625*3150*250mm | 2100*4100*250mm |
| Travelling speed | 40m/min | 40m/min | 40m/min |
| Working speed | 15m/min | 15m/min | 15m/min |
| Spindle power | 9.0/12kw | 9.0/12kw | 9.0/12kw |
| Spindle speed | 24000r/min | 24000r/min | 24000r/min |
| Working voltage | AC380V/AC220V/3PH/50HZ | AC380V/AC220V/3PH/50HZ | AC380V/AC220V/3PH/50HZ |
| Driving system | Delta/Yaskawa | Delta/Yaskawa | Delta/Yaskawa |
| Controller | Syntec/NC-studio | Syntec/NC-studio | Syntec/NC-studio |
| Software | UG,Master Cam,Art Cam,Visual Mill,Type3,Vetric Pro |
| Positioning mode | Pop-up positioning pin | Pop-up positioning pin | Pop-up positioning pin |
| Table structure | T-slot vacuum/T-slot/Vacuum | T-slot vacuum/T-slot/Vacuum | T-slot vacuum/T-slot/Vacuum |
| Tool-magazine | Carousel | Carousel | Carousel |
| Optional | Multi-operation/Automatic-loading&unloading system
Partition table/Vacuum pump,C Axis |
|
|
All of these models can be customized according to customer requirements.
4. Applications
1: Furniture: ideally suitable for processing cabinet door, wooden door, solid wood furniture, panel wood furniture, windows, tables and chairs, etc.
2: Other wooden products: stereo box, computer desk, musical instruments, etc.
3: Well-suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, etc.
4: Decoration: acrylic, PVC, density board, artificial stone, organic glass, soft metals like aluminum and copper, etc.
5. Guarantee and after sale service:
Warrantly;1 year guarantee for whole machine;
In the processing of production,our professional technical engineers inspect the processing to ensure the quality of products.Every machine must be tested before delivery for 8 hours.
After sale service
1:12 months guarantee of the whole machine,
2: Main parts(excluding the consumables and the person damaged) shall be changed free of charge if there is any problem during the warranty period, we will provide the consumable parts at an agency price when you need replacement.
3:Software is on update for free whole life.
4: Our engineer could service you 24 hours online by Skype, msn, QQ, or by cellphone.
5:Our engineer could support you technology to your country if necessary.
6:We will send the English manual and CD video for machine using and maintaining to you with the machine
6:Exhibition in whole world
We participated in many international exhibitions, for example: Shanghai Exposition, Beijing Exhibition, Munich Exposition in Germany, etc.
7:Certification of Machine
Our products has gained CE authentication.
8:FAQ
1. Q: Are you a factory or trading company? Can you introduce your company?
A: We are a factory. Jinan Magic CNC Technology Co.,Ltd is specialized in R &D ,producing CNC router, adverting engraving machine,stone engraving machine,craft engraving machine,multi-head engraving machine.which is leader in the domestic and foreign CNC industry.our product have got CE certificate.
Our machine is mainly equips with Italy,Japanese and Germany original imported parts,it is widely used in wood engraving,metal carving,stone engraving,mold engraving,advertisement engraving,craft,textile leather, package printing, etc industry.
Business philosophy:
Advanced technology- modern CNC laboratory and workshop,
Quality assurance: ISO 9001 quality control system, monitor each production step.choose outstanding person to join our team every year
Good service: carry out better service and resolve customer feedback in time.
Culture feature:create top class quality,top class service, good reputation.customer requirement and recognition is our improving power.
Welcome domestic and foreign customer visit our factory
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Jinan City, Shandong Province, China, about 4 hours train from Shanghai.
All our clients, from home or abroad, are warmly welcome to visit us!
3. Q: How can I get some samples?
A:We are honored to offer you samples.
4. Q: How does your factory do regarding quality control?
A: Quality is priority. JQ people always attach great importance to quality controlling
From the very beginning to the very end.
Our products has gained CE authentication.
