Product Specifications
| Prod Model: |
MP6-156A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
12"-17" |
| Touch Panel: |
Mapletouch 5wire Resistive Touch Panel |
| Mainboard: |
Industrial Mainboard |
| Shell Material: |
Alloy, Metal |
| Extended Function: |
Can Install WiFi |
| Memory Capacity: |
2GB |
| CPU: |
Intel Atom |
| Display Type: |
LCD |
| HDD Capacity: |
160GB |
| Display Screen Size: |
15" |
Product Description
Specification
Model MP6-156(ATOM) MP6-176(ATOM)
Dimension TFTLCD15.1" TFTLCD17.1"
Resolution 1024*768 1280*1024
Color Resolution 16.2M 16.2M
Brightness 250CD/m2 300CD/m2 Contrast Radio 450: 1 500: 1
I/O Connection
VGA port dB-15 port
Controller USB/COM (Optional)
DC Adapter DC12V\5A
Circumstance Condition
Operation Temperature -10 ~ 35degree
Store Temperature -20 ~ 60degree
Optional Fittings
Customer Display Optional
Magnetic Card Reader Optional
Others
Installing ways Hanging, Desktop VESA
Power supply 100V-240VAC
Touch Screen MapleTouch 5-wire Resistive Touch screen(Hitting life: More than 35 million times for each point)
Standard Collocations
Mainboard MP-A270( Intel945GSE Stable performance, superior quality industrial motherboard)
CPU 1.6G(ATOM N270) Without/ with Fan
Memory DDRII 1G
HDD 160G
Audio Interface AC97 Audio
Network Interface 100/1000Mbps high speed Ethernet network (wireless network card optional)
USB port 3 units ( Max for 7 units)
RS232 Port 2 units ( Max for 4 units )
Product Certification FCC, CE, CCC
LPT Port 1 units
Guangzhou yulian electronic technology Co., Ltd. is the mainly professional manufacturer in producing mapletouch POS terminals, industrial control systems and multifunction inquiry touch kiosks in China. We have been an innovative and creative force in the development and manufacturing of high quality, high performance systems since 2000. Now our products have obtained the certificates of ISO9001: 2000, CE, FCC, CCC, CB, ROSH and widely applied to many fields.
