Hyrite Lighting Co. >> 15W 12VDC IP20 Constant Voltage Switching Power Supply

15W 12VDC IP20 Constant Voltage Switching Power Supply

Name: 15W 12VDC IP20 Constant Voltage Switching Power Supply
Brand: china-manufacturer-directory.com
SKU: 756194445
Availability: InStock
Rating: 4.3 (137 reviews)

Supplier:	Hyrite Lighting Co.
Price:	US $ 2.95-3.1/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	OS-622-CV
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Power:	15W Max
Output:	Constant Current
Input Voltage:	100-260V
IP Rating:	IP20 Non Waterproof
Warranty:	2 Years Warranty
Use:	for Spot Light, Down Light, Panel Light
Size:	462620mm
Case:	Plastic
Output Voltage:	12VDC
Operating Temperature:	-25~40 Degree
Usage:	Construction, Building
Circuit Structure:	Electronic Step-down Transformer
Output Type:	Terminal
Driving Method:	Constant Voltage or Constant Current
Certification:	CE, RoHS, EMC Test
Power Supply Voltage:	AC170-260V
Brand:	Neonpro

Product Description

15w 12VDC IP20 constant voltage Switching Power Supply

Brief Introduction:

*Constant voltage and constant current, plastic case, IP20
*Used for Spot Light, Down Light, Panel Light etc
*Protection: Short Circuit, Over Load

Note:
Trade Terms: EXW, FOB, CIF and CNF term available
Lead time: 15 days after order confirmation
Payment terms: L/C, T/T, Western Union
MOQ: 1 pc

Shipping:
* DHL FedEx TNT UPS EMS
* By Sea
* By Air

Technical Specification

Model no.	OS-622-CV
Input voltage	100-260 VAC 50/60 Hz
Max. power	15W max
Output type	Constant Current or Constant Voltage
Efficiency	85%
Output	12VDC or 24VDC
Overload protection	105% hiccup mode, auto-recovery
Over voltage protection	120% rated output voltage
Withstand voltage	I/P~O/P:1.5kVAC, 1 minute
Operating temperature	-25~40 degree
Installation	Non Waterproof
IP rating	IP20
Certificates/standards	CE SAA
Connection input/output	Terminal
Dimensions(LWH)	874320 mm
Packing information	100Pcs/ Carton, G.W 3.5KG
