Product Specifications
| Prod Model: |
NX109 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Wireless Micphone |
| Batch Number: |
2013+ |
| Brand: |
Xuntong |
| Material: |
PCBA |
| Manufacturing Technology: |
Nordic |
| Package: |
Qfn Package for Mainly Chip |
Product Description
2.4GHz Band
Channel 37 Adaptive Frequency Hopping
Data rate 4Mbps
Modulation GFSK
RF Power Max 0dBm
RX Sensitivity -80dBm
Input level Max 1.0Vrms
Output level Max 2.0Vrms
Freq. Response 20-16kHz
THD+N -91dB
Compression 32kHz no compression
Range about 20-30m in open space
Include 1 ATX module 1 ARX module
Voltage supply
Transmitter module 2.4~3.6V
Receiving module 3.0~3.6V
TX current about 19mA
RX current about 36mA
For wireless speaker
XUNTONG TECHNOLOGY Co., Ltd, as an promotor of short range distance wireless communication technology, is the first one who brings the Nordic Semiconductor short range distance wireless products into China Market, and has more than over 12 year's experience in providing professional short distance wireless solution, from chip to solution, and from design to product, you can get into this professional field quickly with no fear of trouble in the rear, we can share the world-lead-class wireless technology together.
XUNTONG TECHNOLOGY Co., Ltd has overall wireless short range distance solution, can meet different application demands:
433/868/915/2400MHz-all range of ISM Band wireless short range solution
2.4GHz high quality wireless digital audio solution, include wireless speaker, wireless headset, wireless microphone
2.4GHz Wireless model car, model airplane, toy solution
2.4GHz wireless tags, active RFID
2.4GHz wireless sport, health, fitness solution
2.4GHz wireless mouse, keyboard, computer peripherals.
