Product Specifications
| Prod Model: |
PT-280 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Style: |
Black and White |
| Usage: |
Thermal Printer |
| Type: |
Thermal |
| Interface Type: |
Bluetooth+USB / WiFi+USB |
| Consumable Type: |
No Need Cartridge |
| Max. Paper Size: |
58mm |
Product Description
Main Features are as below:
Streamlined structure.
Drop in paper loading, easy operation.
Support thermal paper width 58mm, diameter 50mm, thickness 0.06~0.08mm.
Rechargeable lithium battery: 1900mA/7.4V, low resistance, long cycle life.
Power adapter: 9V-1A, AC100-240V. stronger load capacity, support to print receipts when charging the battery.
Low-power mechanism.
Support to print receipts without battery, when connecting to power adapter.
Automatic sleep mode function.
Two kinds of Interface: USB+Bluetooth (standard ), USB+WIFI (optional)
USB+Bluetooth: BT3.0 and BLE4.0, support Android and iOS system.
USB+WIFI: AP/STA/AP+STA mode to set up the networks.
Support USB virtual COM port for developing and testing by developer.
Compatible with ESC/POS printing commands, support NV logo download printing, various 1D barcode and QR barcode.
Receipt printed alert function.
Low power consumption, good print quality, 50km mechanism lifespan.
Support GB18030 Simplified Chinese, Big5 traditional Chinese, Japanese, Korean, international character set and extended code pages.
LED indicator (standard), LCD display(optional)
LED can be showed abnormal condition of the printer, battery capacity, charging and connection status ect.
LCD can be showed the printer work status more directly.
Applications:
Takeaway receipt
Taxi / Train fare receipt
Tax collection
Postal receipt
Table side ordering for Restaurant
Online payment information note
Customer receipt
Work order
Direct Store Delivery note
Parking citation / Traffic violation ticket
| Printing | Print method | Direct thermal line |
| | Print width | 48mm |
| | Dot density | 384dot/line |
| | Print speed | 60mm/s |
| | Interface | USB+Bluetooth/USB+WIFI |
| | Paper width | 58mm |
| | Paper diameter: | 50mm |
| | Paper thickness | 0.06~0.08mm |
| | Print commands | Compatible with ESC/POS |
| | Fonts | GB18030, Big5, Japanese, Korean |
| Barcode | Character Size | ANK Font: FontA: 12*24dots |
| | | FontB: 9*17dots |
| | | Simplified/Traditional Chinese Character, Japanese, Korean: 24*24dots |
| | Barcode mode | UPC-A,UPC-E,EAN(JAN)13,EAN(JAN)8,CODE39,CODABAR,ITF,CODE93,CODE128 |
| Buffer | Data | 4K bytes |
| | NV Flash | 60K bytes |
| Physical properties | Dimension | 148.5*86*58.5mm |
| | Weight (including battery) | 288g (Battery: 98g) |
| Power | Power adaptor | input: AC220V output: DC 9V/1A |
| | Lithium battery | 1900mAh/7.4V |
| | Charge period | 2.5h-3h |
| Environment | Work environment | Temperature: 5~45ºC, Humidity: 10~80% |
| | Storage environment | Temperature: -10~50ºC, Humidity: 10~90% |
| Reliablity | Mechanism | 50km |
Zhuhai Gain Electronic Technology Co.,Ltd specializes in producing receipt mini-printers, including thermal line printers, and impact DOT-matrix printers. As a large receipt printer manufacturer in China, our company has come up to advanced domestic level on the aspect of development, production technology and quality control. And in the worldwide markets, we have good reputation as the leader in POS printers and OEM mechanisms.
With expanding business and increasing customer demands, we'll be more devoted to both product innovation and quality improvement. Backed up with strong R&D capabilities, we are capable of launching new products regularly to catch up with the fast-moving markets.
For more information of our company and products, please visit our website and contact us now, we are ready to supply the best service for you.
