2 Layers PCB Immersion Gold Circuit Board with Fr-4 1.0mm

2 Layers PCB Immersion Gold Circuit Board with Fr-4 1.0mm
Supplier: Bestech Circuits Inc.
Price: Negotiable/Piece
Min Order: 1/Piece
Quantity::
Trade Terms: FOB,CIF,DAP
contact supplier

Product Specifications

Prod Model: BestechD001
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Rigid Circuit Board
Dielectric: FR-4
Material: Fiberglass Epoxy
Flame Retardant Properties: V0
Brand: Bestech

Product Description

2 Layers PCB Circuit Board with Fr-4 1.0mm, 1/1 Oz, Copper Thickness, Green Solder Mask
Our capability:
Layers: 1-26 layers
Material: Standard FR1, FR4, CEM1.
High performance material (Teflon (PTFE), Rogers series)
Metal-backed PCBs(alum board, cu based board)
High Temperature.

Surface finish: HSAL, Lead free HASL, Gold plating, Gold-fingers,
Immersion silver, OSP, Immersion gold, Immersion Tin,
Peelable mask, Carbon ink.
Via type: Through holes
Blind/buried via
PCB  Manufacture  Capability
Item    Manufacture  Capability
Layers    1-26  Layers
HDI  2+N+2
Material  Types  Fr-4,   Fr-5,   High-Tg,   Aluminum  Based  , Halogen  Free,
Isola,   Taconic,   Arlon,   Teflon,   Rogers,
Max.   Panel  Dimension 39000mil  *  47000mil  (1000mm  *  1200mm)
Outline  Tolerance  ± 4mil  (± 0.10mm)
Board  Thickness 8mil-236mil  (0.2  -  6.0mm)
Board  Thickness  Tolerance  ± 10%
Dielectric  Thickness  3mil-8mil  (  0.075mm-0.20mm)
Min.   Track  Width  3mil  (  0.075mm  )
Min.   Track  Space 3mil  (  0.075mm  )
External  Cu  Thickness  0.5  OZ  -  10  OZ  (  17um  -  350um)
Internal  Cu  Thickness    0.5OZ  -  6OZ  (  17um  -  210um)
Drilling  Bit  Size  (  CNC  )  6mil-256mil  (  0.15mm  -  6.50mm)
Finished  Hole  Dimension        4mil-236mil(0.1mm  -  6.0mm)
Hole  Tolerance ± 2mil  (± 0.05mm)
Laser  Drilling  Hole  Size    4mil(0.1mm)
Aspect  Ration  16: 1
Solder  Mask Green,   Blue,   White,   Black,   Red,   Yellow,   Purple,   etc.
Min  Solder  mask  Bridge 2mil(0.050mm)
Plugged  Hole  Diameter 8mil-20mil  (  0.20mm-0.50mm)
Beveling 30o  -  45o
V-scoring +/-0.1mm,   15o    30o    45o    60o
Impedance  Control                                Min. 5%    General  ± 10%
Surface  Finishing  HASL,   HASL(lead  Free),   Immersion  Gold
Immersion  Silver,   OSP,   Hard  Gold  (  up  to  100u" )
Certification UL  RoHS  ISO9001: 2000  ISO14000: 2004  SGS
Testing Flying  probe, E-TEST,   X-RAY  Inspection  , AOI
Files Gerber  Protel  DXP  Auto  CAD  PADS  OrCAD  Express  PCB  etc

Bestech circuits (HK) Limited is a World Class manufacturer of printed circuit boards (PCBs) in China. Provides the electronics industry with high quality, low cost PCB's free of defects, fast, quick, and on-time. This equates to unparalleled value by exceeding our customer's expectations in service, quality, delivery, and cost-effectiveness.

We offer an effective engineering, design and manufacturing service for the electronic industry. Our customers select us since we're able to provide a high quality and flexible service that offers an enhanced product, cost-effectively, while at the same time we take a variety of complex design criteria into account.

We act as an extension to your in-house capabilities for your manufacturing needs. The personal attention and flexible working relationship you will experience is a key to meeting your time to market needs. Your single point of contact will ensure that the services required are built with quality and functionality, while costs are driven down with dynamic engineering for product improvements.

Bestech goal is to provide customers with real-time support to meet today's fast-paced demands and market pricing pressure.

Our Philosophy:

Our success is achieved through on-time delivery, excellent service, and commitment to YOUR project.

Customers are our partners, we succeed together.
