Product Specifications
| Prod Model: |
VT-8021Z |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| IR Distance: |
15~50m |
| Lens: |
2.8, 3.6, 6, 8, 12, 16 Mm Optional |
| Material: |
Metal |
| TV System: |
PAL / NTSC |
| Type: |
Monitoring System |
| Technology: |
Infrared |
| Feature: |
Waterproof / Weatherproof |
| Sensor: |
CCD |
| Horizontal Resolution: |
420tvl |
| Application: |
Fixed Focus Camera |
| Kind: |
Fixed Focus Camera |
Product Description
2 PCS LEDs CCTV Array IR LED Camera with CE/FCC, Waterproof HD Camera, 3 years warranty
Product Advantage
1.85mA low current design, extend working life
2.9V-21V wide voltage design, more stable working and lower fault
3.3000V lightning and surge current protection circuit design
4. Six layer PCB circuit board
Feature:
1. Waterproof Fixed focus IR camera + OSD
2. IR Distance15~50 m
3.2 PCS array LED
4. Dual glass, no IR diffusion and fog
5. IP66, indoor/outdoor installation
6. Easy plug bracket
7. One button for OSD
8. Cable-managed Bracket: To prevent external force of destruction such as cutting
9. Fixed focus lens: 2.8/3.6/6/8/12/16 mm optional
10. Professional security camera with 1/3'' Sony CCD sensor 420 TVL
11. Power: DC12V± 5%
12. Operation Temperature: -20º C~50º C
13. S/N Ratio: ≥ 52dB (AGC OFF)
14. Electronic Shutter Speed: 1/50(1/60)-1/100000S
15. Suitable for any low illumination environment, Convenient installation (bracket contain)
About us:
We, Shenzhen Big Sealion Electronic Technology Co., Ltd, established in 2005 and specialized in security and surveillance equipment production. Owning R&D team and strongly technical support, combining the advanced technology and management, we can provide you more competitive products (All products with CE, FCC, RoHS certificated)
Order Arrange:
1. No MOQ limited, sample order is ok.
2. Delivery time: 2-3days for sample order and 5-15days for formal order depends on the qty after payment.
3. Package: 1PC/color gift box
4. Trade term: EXW, FOB, CIF
|
What we promise before order |
What you can get after order |
* offer the most competitive products
*effective and professional communication
* high quality control and prompt delivery
* 3 years warranty
* OEM/ODM service |
* Glass enclosed by 1%
* Lines/ wires enclosed by 5%
* Packing box enclosed by 1%
* Sample lead time: 2-3days for standard, 7-10days for special
* production lead time: 25days for 500pcs |
