20" Kiosk Touch Screen (UTSU-201M-4B)

Supplier:	Beijing IT01 Co., Ltd.
Price:	US $ 50-100/Piece
Min Order:	50/Piece
Quantity::
Trade Terms:	CIF

Product Specifications

Prod Model:	UTSU-201M-4B
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
OS:	Winxp, Win7, Linux
Connection Port:	USB/COM

Product Description

Benefits:
* Pure glass touch screen with superior image clarity, high resolution, high light transmission ratio.
* Durable, scratch-resistant glass surface, work in order even scratched.
* Good stableness without drift, automatic correction, accurate operation.
* Long service life, over 50 million touch times in one location without failure.

Applications:
*Kiosk in high-threat environments
*Ticketing machines
*Gaming machines
*Post-Of-Sales
*Post-Of-Information

UTouch SAW touch screen products list
Size	Model	Type	Aspect Ratio	Thickness (mm)	External Dimension	View Area Dimension	Active Area Dimension
					L3*W3 (mm)	L2*W2 (mm)	L1*W1 (mm)
20inch	UTSU-201M-4B	Standard	16: 10	4	469*306	438*274	432*268

Specifications

Touch Technology

Surface Acoustic Wave(SAW) Touch Technology

A. Mechanical

Input Method

Finger, gloved hand

Available Size

8.4” -32”

B. Electrical

Positional Accuracy

Standard deviation of error is less than 0.080 in. (2mm)

Resolution

Touchpoint density is based on controller resolution of 4096x4096; Plus 255 levels corresponding to touch pressure.

Touch Activation Force

Typically 100g

Controller

Serial (RS232) or USB

C. Optical

Light Transmission

Up to 98%

D. Environmental

Temperature

Operating: - 20° C to 50° C; Storage: -40° C to 71° C

Relative Humidity

Operating: 4 0° C at 10%~90% RH. Non-condensing

Altitude

3000M

Chemical Resistance

The touch active area of the touch screen is resistant to chemicals that do not affect glass, such as: acetone, toluene, methyl ethyl ketone, isopropyl alcohol, methyl alcohol, ethyl acetate, ammonia-based glass cleaners, gasoline, kerosene, vinegar.

Electrostatic Protection

Per EN 61000-4-2.1995: Meets level 4(15kV air/8kV contact discharges)

Stability

Can be sealed to meet NEMA 3/3R/5/12/12K/13. IP64 standards

E. Durability

Surface Durability

Surface durability is that of glass. Mohs’ hardness rating of 7

Expected life

No known wear-out mechanism, as there are no layers, coatings or moving parts. Utouch technology has been operationally tested to more than 50 million touches in one location without failure, using a stylus similar to a finger.

Warranty

Touchscreen: 3-year limited warranty Controller: 3-year limited warranty

Agency Approvals

CE, FCC
