200HP China XCMG Motor Grader Gr200

Name: 200HP China XCMG Motor Grader Gr200
Brand: china-manufacturer-directory.com
SKU: 702940602
Availability: InStock
Rating: 4.8 (72 reviews)

Supplier:	Jinan Sinoheng Import and Export Co., Ltd.
Price:	US $ 30000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	gr200
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Engine Model:	Shangchai Sc8d200g2b1
Rated Power/Speed:	147kw/2300rpm
Dimension(Lxwxh):	8932X2625X3470mm
Operating Weight(Standard):	16000kg
Ground Clearance:	430mm
Walking Mode:	Wheeled
Load And Unload Method:	Front Discharge
Certification:	ISO9001: 2000
Condition:	New
Type:	Motor Grader

Product Description

XCMG GR200 Motor Grader with front dozer
Specifications

200HP XCMG GR200 Motor Grader
1. Shangchai engine, 147 KW
2. Imported differencial
3. Moldboard width * height: 4270*610mm

Basic specification
Engine model	SHANGCHAI SC8D200G2B1
Rated power/speed	147kW/2300rpm
Dimension(LxWxH)	8932×2625×3470mm
Operating weight(Standard)	16000kg
Performance specification
Travelling speed ,forward	5,8,11,19,23,38 km/h
Travelling speed ,reverse	5,11,23 km/h
Tractive force(f=0.75)	87KN
Max. gradeability	25%
Tire inflation pressure	260 kPa
Working hydraulic pressure	18 MPa
Transmission pressure	1.3~1.8MPa
Operating specification
Max. steering angle of front wheels	±49°
Max. lean angle of front wheels	±27°
Max. oscillation angle of front axle	±7.3°
Max. oscillation angle of balance box	4500
Frame articulation angle	±500°
Min. turning radius	90m
Biade
Maximum lift above ground	28-70mm
Maximum depth of cutting	360mm
Maximum blade position angle	90°
Blade cutting angle	±17°
Circle reversing rotation	±15°
Moldboard width X height	4270×610mm
Tire	17.5-25
Ground Clearance	430mm
Tread	2156mm
Front axle and Rear axle distance	6219mm
Tread between mid tire and rear tire	1538mm

Packaging & Shipping

1 unit per 40HQ container. If the clients do not want to disassemble the wheel loader, we can deliver it by RORO ship.

Our Services

1.Warranty: 1 year
Within warranty, we offer the spare parts free of charge. After warranty, we offer you the original XCMG spare parts with only cost price.


2. We have a professional engineers and technicians available at your service.

Company Information

We are specialized in exporting XCMG construction machinery. Our machines have been widely exported to South America, Middle East, Europe and Africa etc.and has gained great popularity and credit among the overseas users for its strong quality and competitive price.
If you are interested in XCMG products pls do not hesitated to contact me. We will offer you with the best price and service.

SINOHENG is a professional exporter of construction machinery in China, working with government manufacture of XCMG and SINOTRUK. On the basis of the Groups, we export the construction machinery more than 100 countries. We always help our customers find the most suitable machines according to customer local market. From us, you could get all the construction machinery you need at earlier time. In the meanwhile, you could enjoy the most competitive price, strong quality and sales service here. We sincerely welcome you contact us for cooperation!

1. Loader: Engine power: 25HP-532HP
Bucket capacity: 0.3m3-6.5m3
Rated load: 800kg-12000kg
Main product: wheel loader, skid steer loader, mini loader, backhoe loader, etc

2. Crane: Lifting weight: 5ton-2000ton
Main product: truck crane, rough terrain crane, truck mounted crane, crawler crane, all-terrain crane, tire crane, etc

3. Dump truck, tractor truck, mixer truck, semi trailer, container transport semi trailer, concrete mixer semi trailer, tanker transport semi trailer, wrecker truck and other different series.

Other series of construction machinery: forklift, motor grader, road roller (compactor), excavator, concrete pump, telescopic handler, etc
