Product Specifications
| Prod Model: |
ZY-B200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lamp: |
200W Phllip UHP Project Lamp |
| Power Consumption: |
250W |
| Lens: |
(Yilong) 3in1 Optical Group Combination |
| Dimming: |
0-100% Linear Adjustment |
| Prism: |
8 or 16 Rotating Facet Prism Optional |
| Beam Angle: |
0-3.8 Degree |
| Gobos: |
1 Gobos Wheel with 17 Fixed Gobos+Open |
| Operation Temp: |
-20 Degree to 40 Degree |
| N/W: |
17 |
| Package: |
Carton Box or Flight Case |
| Strobe: |
Adjustable Speed Strobe |
| IP Rating: |
IP20 |
| Certification: |
CE |
| Light Source: |
Project Lamp |
| Material: |
Plastic + Steel |
| Emitting Color: |
14 Colors + Open |
| Control Channel: |
16/20CH |
| Control Mode: |
DMX512,Automatic and Master/Slave Mode |
| Voltage: |
90-240V |
Product Description
Features:
1. Phillip 190W Lamp2. High brightness, Fast moving speed, Pefect low noise
3. 8 or 16 or 24 facet rotation prism optional
4. 2 years warrantyModel Number: ZY-B200
Lamp Source
Phillip 190W Lamp
Color temperature: 8,500K
Acerage Life: 2,000Hrs
Electrical
Input Voltage: AC90-240V 50/60HZ
Power Consumption: 250W
Control
Display:LCD display, can be turned 180°&record the using time
Control Protocol: DMX512,automatic and master/slave mode
Channel: 16/20CH
Optical System
YL(YiLong) 3in1 optical group combination
Dimming: 0-100% linear adjustment
Strobe: heat-proof plastic+module pressing alloy materials
Focus: ELectronic
Prism: 8 or 16 or 24 facet prism optional
Frost filter
Beam angle: 0-3.8 degree
Movement
Pan:540°
TilL:270°
Pan/Tilt Resolution: 16bit
Gobos&Colors
Gobos: 1 gobos wheel with 17 fixed gobos+open
Colors: 1 color wheel with 14 fixed colors+open
Physical
Housing: Flame-retardant plastic
Housing Color: Black or White selectable
Fixture Connection: 3-Pin DMX in&out, power in
Cooling: Quiet cooling fan and aluminum radiator
Certificate&Satety
Certificate: CE
Working environment: Indoor
Operation temp:-20~40ºC
Packing
Accessories: Standard power cable, signal cable and omega
Optional safety cable and clamps
Product Size: 335*305*475mm
Carton Size: 410*440*540mm
Dula case:850*480*710mm
N.W.:17.00KGs
G W.:19.5KGs
Carton box or flight case package
Guangzhou CN Eagle Lighting Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments.
The main products include moving head beam, LED stage light, follow spot, LED PAR Lights etc.
We own a professional R&D team, who has about 10 more years experience in stage lighting.
Our sales team can provide best service by engineers and technical staff members' supporting.
Most of our products have passed CE quality management system standard as well.
There are numerous domestic projects we have been undertaken, was praised by all the customers.
Our main products are 200W/230W/280W/330W 5r/7r/10r/15r moving head beam, 19 X 15W bee eye LED moving head, 36/37 X 15W LED moving head, 54 X 3W LED PAR/ non-waterproof LED PAR,
8 X 12W LED moving spider light etc,
Our lighting are suitable for stage event, concert, studio, night club, disco, architectural, karaoke television we currently provide comprehensive service and customer support to over 40 international countries and regions.
We offer high quality products, best after-sales service, fast shipment.
Customer First! We always strive to exceed the customer's expectation. We go thogether to become the leading stage lighting supplier on a global maket.
