200W Sharpy Light Stage Lighting

Product Specifications

Prod Model:	AL-G200
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lamp Source:	189W Lamp
Control:	Auto, Sound Actived, DMX, Master/Slave
Movement:	540°/270°
Packing Size:	420*480*580mm
Beam Angle:	0-3.8
Input:	AC90-240V
Rotating Gobos:	1 Gobo Wheel with 17 Fixed Fixed Gobo+Open
Colors:	1 Color Wheel with 14 Fixed Colors+Open
Fixture Connection:	3-Pin DMX in&out, Power in
Cooling:	Quiet Fan Cooling
Light Source:	Gas Discharge Bulb
Strobe:	Electronic Strobe
Control Mode:	Dmx Signal Control
IP Rating:	IP44
Certification:	RoHS
Voltage:	220V
Control Channel:	16/20

Product Description

Good Quality Moving head beam 200 5R,beam moving head 200w

AL-G200


Technical Parameters:
Lamp Source:
Yodn MSD189W R5/Philips
Color temperature: 8, 500K
Arerage Life: 2, 000Hrs
Input Voltage: AC90-240V 50/60Hz
Power Consumption: 250W
Control Method: DMX512, automatic and master/Slave
Channel: 16/20 CH
Display: 4-button LED digital/LCD display selectable
Optical: YiLong 3in1 optical group combination
Dimming: 0-100% linear adjustment
Strobe: Heat-proof plastic+module pressing alloy materials
Focus: ELectronic
Prism: Rotating 8-facet prism
Frost
Filter
Beam angle: 0-3.8 degree
Movement:
Pan: 540°
TilL: 270°
Pan/Tilt Resolution:
16bit
Gobos&Colors
Rotating Gobos: 1 gobo wheel with 17 fixed gobos+open
Colors: 1 color wheel with 14 fixed colors+open
Fixture Connection: 3-Pin DMX in&out, power in
Cooling: Quiet cooling fan

Packing Size:
Accessories: Power cable, signal cable
Omega safety cable and clamps
Product Size: 330*390*490mm
Packing Size: 420*480*580mm
N. W.: 17.00KGs
G W.: 19.5KGs

For more informaiton, please email, call or visit us.
