Shanghai Keno Industrial Co., Ltd. >> 2014 High Speed Full Automatic Juice Filling Machine (KENO-F201)

2014 High Speed Full Automatic Juice Filling Machine (KENO-F201)

Name: 2014 High Speed Full Automatic Juice Filling Machine (KENO-F201)
Brand: china-manufacturer-directory.com
SKU: 721632065
Availability: InStock
Rating: 4.7 (31 reviews)

Supplier:	Shanghai Keno Industrial Co., Ltd.
Price:	US $ 21980/Piece
Min Order:	1SET
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	KENO-F201
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Keno:	Keno
Automatic Grade:	Fully Automatic
Structure:	Rotary
Feed Cylinder Structure:	Multi-Room Feeding
Material Type:	Liquid
Type:	Weighing-type Filling Machine
Filling Valve Head:	Multi-Head
Packaging Container Lifting Structure:	Pneumatic Lifting
Filling Principle:	Pressure
Packaging Type:	Bottle
Dosing Device:	Plunger
Packaging Material:	Bottle and Cap

Product Description

High speed high speed juice filling machine

Carbonated Drink 3 In 1 Washing filling and capping machine

Usage Characteristic:

This series equipment is used in production gas containing water of PET polyester bottle-packing carbonated be vorage, such as Coca cola, Pepsi-cola, Sprite drink etc.
It carries out washing bottle, filling and capping on one machine. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient. It adopts bottle handing technology to make changing bottle more convenient, faster and easier. The main machine adopts advanced PLC control, Touch screen and no-bottle, no-cap system The key electric elements are from famous international brand.

Main Technological Data:

Model	16-12-6	18-18-6	24-24-8	32-32-10	40-40-12
Production capacity	2000-3000	3000-5000	5000-7000	7000-10000	10000-15000
Filling precision	≤+5mm(Liquid Level)
Filling pressure (MPa)	≤0.4
PET bottle specification(mm)	(Bottle Diameter):φ50-φ110;(Height):150-310
Suitable cap Shape	Plastic Screw Cap
Total power (kw)	4.4	5.2	6.2	6.2	7.5
Weight (kg)	2500	3500	4500	6000	7200
Overall dimensions(mm)	2250x1650x2250	2600x1965x2250	2980x2200x2250	3880x2200x2250	4000x2250x2500

Shanghai Keno Industrial Co., Ltd. is an integrated corporation of science research, design, manufacture and sale. We have manufactured all kinds of machinery and materials for many years, such as filling machinery, computerized cutting machinery, printing machinery, labeling machinery, pallet wrapping machinery, heat shrinking wrapping machinery, strapping machinery, PE stretch films, BOPP tapes, PET straps and other related equipment.

Our company was established in 1995 and covers an area of 25000 square meters. Through over 10 years of hard work and development, our production scale has been expanding. We always provide the top quality and the best after-sales service for our customers. Of course, we also ensure our prices are more competitive than prices of other suppliers.

In August of 2000, we attained ISO9001 certification issued by the SGS. We have a strict quality control system. We supervise all the production processes from material purchasing, processing and storage to delivery. By these means, we can ensure the quality of our products. Our quality control is carried out according to the international standard.

Our products are not only very popular in domestic market, but also are exported to Southeast Asia, the Middle East, Europe, South and North America and Africa. As a pioneer in this field, we have accumulated plenty of experience in all aspects of production, sale, and service of packing machinery. If you are interested in any of our products, please feel free to contact us for further information. We sincerely welcome customers from both at home and abroad to cooperate with us to develop friendly and mutually beneficial business relationships.
