Product Specifications
| Prod Model: |
carbonated drink filling machine |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Stainless Steel |
| Delivery Time: |
40days After Payment |
| Shipment Terms: |
by Sea or by Train |
| Certification: |
CE, ISO |
Product Description
Description:
Carbonated Beverage Filling Machinery are manufactured by advanced technology, and we have completely equipment, so they enjoy fast sales. The filling line combines rinsing bottles, filling bottles and capping bottles together with PLC control. It is mainly used for plastic bottles with carbonated beverages and non-carbonated beverages.
Characteristic of machine:
1. All parts contacting with beverages adopt top grade stainless steels whose surfaces are polished till smooth for easy rinsing. The sealing materials are EPDM rubber.
2. Carbonated beverage filling line/carbonated drink machine/carbonated filling machine/carbonated beverage machinery/carbonated filling line
3. Adopt PLC as center control, make use of pressure transmitter and electromagnetism pneumatic valve to measure liquid level, keep balance of filling pressure to insure stable liquid level.
4. Adopt new type filling valves which are especially designed for plastic bottles. The returned air and the liquid in filling tank are insulated to insure cleanliness of the filled beverages.
5. Adopt advanced magnet clutches for capping with adjustable torsional moment to insure capping safely and reliably.
Advantages of csd filler, csd filling line
A. High automation level, compact structure, attractive appearance, convenient and simple operation, safe and reliable and adjustable continuous production capacity, low labor intensity.
B. The main machine adopts advanced PLC control technology
C. The key electric elements adopt products made by international famous companies, such as Mitsubishi and Siemens.
These series carbonated drink filling machine can handle max 3 liter pet bottle. Welcome to inspect Carbonated Drink Filling Machine in our factory.
| Model RFC-W series | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 |
| Washing-Filling-Capping | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 |
Producing capacity
(600ml) | 2000-4000
(bph) | 5000-7000
(bph) | 8000-12000
(bph) | 12000-15000
(bph) | 16000-20000
(bph) | 20000-24000
(bph) | 25000-30000
(bph) |
| Applicable bottle (mm) | φ=50-108 H=170-340 330ml-2.25L |
| Pressure (kg/cm2) | 2~3 |
Outside vacuum
pump power (kw)
| Main motor
1.5kw | Main motor
2.2kw | Main motor
3kw | Main motor
4kw | Main motor
7.5kw | Main motor
9.5kw | Main motor
12kw |
Overall dimension (mm)
(LxWxH) | 2100x1400
x2700 | 2460x1720
x2700 | 3100x2100
x2700 | 3500x2500
x2700 | 4600x1800
x2700 | 5200x4500
x2700 | 6500x4500
x2700 |
| Weight(kg) | 2500 | 3500 | 4200 | 5500 | 6800 | 7600 | 9800 |
