Machinery Factory Of Gongyi City >> 2015 Processing Ore Equipment Jaw Crusher (PEX-300*1300)

2015 Processing Ore Equipment Jaw Crusher (PEX-300*1300)

Name: 2015 Processing Ore Equipment Jaw Crusher (PEX-300*1300)
Brand: china-manufacturer-directory.com
SKU: 698146512
Availability: InStock
Rating: 4.8 (28 reviews)

Supplier:	Machinery Factory Of Gongyi City
Price:	US $ 9999set
Min Order:	1set
Quantity::
Trade Terms:	FOB,EXW,CIF

Product Specifications

Prod Model:	PEX-300*1300
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Equipment:	Iron Ore Processing Equipment
Mining Equipment:	Jaw Crusher
Crusher:	Stone Crusher
Feed Size(Mm):	300*1300
Input Size(Mm):	250
Capacity (T/H):	20-90
Power (Kw):	55
Weight(Kg):	11
Type:	Jaw Crusher
Application:	Stone Industry
Drive:	Electric
Crushing Style:	Grinding & Impact
Crushing Degree:	Coarse Crusher
Finished Surface:	Outer Surface Process
Color:	According to Customers ' Needs

Product Description

Machinery Factory of Gongyi City:http://www.gymineralprocessing.com
fixed-line telephone:86-0371-64324031 85603988
FAX:86-0371-64324051
Add:Gongyi City,HenanProvince, Kangdianzhen goverment one kilometer south
contacts:Sir ma;Tel:18538037601
We will offer warm-hearted service to you

Introduction of the Iron ore processing equipment:
The overflow type ball mill by feeding department, the material department, rotary department, transmission department (reducer, small transmission gears, motor, electric control) and other major parts. Hollow shaft with steel castings, lining systems can be, return big gear with cast roll teeth processing, the cylinder body set have wear-resisting lining board, has good abrasion resistance. Iron Ore Pellet Plant This machine is smooth operation, reliable.
Theworking principle of Iron ore processing equipment:
The overflow type ball mill is horizontal cylinder rotating device, the outer gear transmission, two warehouse, grid type relief type ball mill. Iron ore processing equipment The material is feeding device the hollow shaft into the material spiral evenly into the mill first storehouse, the warehouse liner or there were steps corrugated linings, with different specifications in steel ball, cylinder rotating centrifugal force will produce steel ball to a certain height down after, to material produced thumping and abrasive. Ore Dressing Equipment The material in the first storehouse reach coarse grinding, through the single diaphragms in the second class, in the warehouse with flat lining board, with steel ball that will further grinding materials. Powder which through the unloading Bi board eduction, finish grinding homework.

The overflow type ball mill is in the material wet water condition of grinding machine work, and dry type ball mill biggest difference lies in the cover for cone, cover only a wave linings, adopts the high quality for the high manganese steel lining board, wear-resisting, low noise and high efficiency. The biggest advantage is that it can choose low grade high magnetic iron ore, can choose any size, can always rejected coarse grain of tailings. The equipment investment low, quick effect.
The overflow type of ball mill is widely used in cement, Portland products, new building materials, refractory material, chemical fertilizer, black and non-ferrous metal processing and glass ceramics production industry, especially in the processing industry used the most common in the grinding machines.

Technical parameters of jaw crusher

Model	Feed opening (mm)	Max.feeding size (mm)	Adjusting range of discharge opening (mm)	Processing capacity (t/h)	Rotation speed of eccentric shaft (r/min)	Motor power (kw)	Total weight (t)	Dimensions (L×W×H) (mm)
PE-150×250	150×250	125	10-40	1-3	250	5.5	0.8	720×660×850
PE-200×300	200×300	180	15-50	2-6	260	7.5	1.2	910×750×990
PE-200×350	200×350	180	18-70	3-10	260	11	1.5	1000×870×990
PE-250×400	250×400	210	20-60	5-20	300	15	2.8	1300×1090×1270
PE-400×600	400×600	340	40-100	16-60	275	30	7	1730×1730×1630
PE-500×750	500×750	425	50-100	40-110	275	55	12	1980×2080×1870
PE-600×750	600×750	500	150-200	80-240	275	55	15.8	2070×2000×1920
PE-600×900	600×900	500	65-160	50-180	250	55	17	2190×2206×2300
PE-750×1060	750×1060	630	80-140	110-320	250	110	29	2660×2430×2800
PE-800×1060	800×1060	640	130-190	130-330	250	110	29.8	2710×2430×2800
PE-830×1060	830×1060	650	160-220	150-336	250	110	30.7	2740×2430×2800
PE-870×1060	870×1060	660	200-260	190-336	250	110	31.5	2810×2430×2800
PE-900×1060	900×1060	685	230-290	230-390	250	110	33	2870×2420×2940
PE-900×1200	900×1200	750	95-165	220-450	200	110	52	3380×2870×3330
PE-1000×1200	1000×1200	850	195-265	315-500	200	110	55	3480×2876×3330
PE-1200×1500	1200×1500	1020	150-350	400-800	180	160-220	100.9	4200×3300×3500
PE-1500×1800	1500×1800	1200	220-350	500-1000	180	280-355	122	5160×3660×4248
PE-1600×2100	1600×2100	1500	300-400	1300-2200	160	350-380	150.6	6210×4013×4716
PEX-150×750	150×750	120	18-48	8-25	320	15	3.8	1200×1530×1060
PEX-250×750	250×750	210	25-60	13-35	330	30	5.5	1380×1750×1540
PEX-250×1000	250×1000	210	25-60	16-52	330	30	7	1560×1950×1390
PEX-250×1200	250×1200	210	25-60	20-61	330	37	9.7	2140×1660×1500
PEX-300×1300	300×1300	250	20-90	16-105	300	55	15.6	2720×1950×1600

Gongyi City Machinery Factory (original Kangdian machinery factory, Gong County Machinery Factory) has large and medium-sized equipment 365 sets, 384 employees, consists of six department: Tachnical department, production department, sales department, domestic trade department, international trade department, service department. There are 240 high-intermediate grade technical personnel. It covers an area of 38, 600 square meters, building area is 18, 000 square meters, fixed assets is 28 million yuan. Gongyi City Machinery Factory is locaded in Kangdian town. One kilometer to south of Kang million eatate Scenic and Kangzhuang road. It is in the east of the provincial capital of Zhengzhou city, there is Hulaoguan Three Kingdoms Battlefield Site; West of Luoyang which is ancient capital of nine dynasties, there is longmen Grottoes which is one of China four famous cave; South of the songshan mountain, there are shaolin Temple and songyang Scademy; North of the Yellow River, there is Sihe yanliu scenic district; Lianhuo Expressway, the Longhai Railway zhengzhou-Xi′ An high-speed rail pass through from east to west, Yellow River bridge line pass through south to nouth. Location is good and transportation is convenient.

Since the factory is established in 1958, it first past the ISO9001 2000 international certification, and obtained import and export license eligibility. Now the leading product are beneficiation series, sandstone series, drying series, milling series eqipment. The products sell well in more than 20 provinces, municipalities and autonomous regions, famous in China, and exporten to many countries southeast Asia, Africa. Quality is enterprise′ S life, we will achieved recognition and satisfaction of the customer through excellent products and quality service. AN oeder is positive, one hopes is a responsibility. No matter it is in the before-sales, during sales or after -sales, we always offer the most attentive service to make you comfortable, let you succeed, also make you satisfied. Cooperating with Gongyi City Machinery Factory will make you no regrets!

Make friends all over the world, invite world content. Gongyi City Machinery Factory sincerely welcome friends from all walks of life to visit and guide, putting forward valuable advice, dicussing cooperation intention, joining hands to creating a better tomorrow.
