(I). Technical parameter:
Raw material: Waste paper and pure wood pulp
Output paper: Kraft paper
Weight: 130-300G/M2;
Capacity: 20-25T/D
Net paper width: 2100mm
Wire width: 2450mm
Rail gauge: 2900mm
Drive way: Speed adjustment in AC frequency &processing transmission
Work speed: 80-120m/min
(II). Main frame of equipments:
1. Cylinder part: Φ 1250mmx 2450mm x 2900mm stainless steel plate style cylinder mould 3 PCS, Φ 450mm x 2450mm x 2900mm couch roll 3 PCS, Φ 450mm X 2450mm x 2900mm reverse roll 1 PC, rubber hardness HSD 80° ± 2,
2. Press part: Φ 600mmx 2450mm x 2900mm rubber roll 2PCS, rubber hardness HSD 92° ± 2, Φ 650mm x 2450mm x 2900mm natural marble stone roll 2 PCS, pneumatic loaded device.
3. Dryer part: Φ 1500mm x 2450mm x 2900mm alloy dryer can 6 PCS, it is equipped with dry mesh device.
4. Calendar part: Three rolls calander 1set, bottom roll Φ 400mm x 2450mm x 2900mm, Middle rollΦ 250mm x 2450mm x 2900mm, Rearward roll: Φ 300mm × 2450mm x 2900mm
5. Reeling part: Φ 900mm reeling machine
|
No |
Item |
Power
(kw) |
Grade |
Qty
(set) |
|
1 |
2100mm multi-dryer can multi-cylinder mould paper machine |
|
|
1 |
First main Press part |
30 |
4 |
1 |
Secondary main Press part |
22 |
4 |
1 |
Cylinder group |
11 |
4 |
1 |
|
2 |
Exhaust hood of dryer group |
|
|
1 |
|
3 |
Axial flow fan |
7.5 |
4 |
1 |
|
4 |
Style 15 roots pump |
15 |
4 |
2 |
|
5 |
Suction box |
|
|
5 |
|
6 |
2100mm calender machine |
11 |
4 |
1 |
|
7 |
2100mm reeling machine |
7.5 |
4 |
1 |
|
8 |
AC frequency controller |
|
|
1 |
|
9 |
Working table |
|
|
1 |
|
10 |
Air pump |
|
|
1 |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
