Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: |
415V |
| Weight: |
<50 tons |
| Type Of General Rubber Machinery: |
Mixing Roll |
| Type Of Tire Machinery: |
Rubber Regeneration Machinery |
| Certification: |
ISO, CE |
| Power: |
>100KW |
| Using Life: |
≥15 Years |
| Customized: |
Customized |
| Type: |
General Rubber Machinery |
Product Description
Usage:Open mixing mill (mill for rubber) referred to the mill or mixing machine, also known astwin-roll kneader. Placed by two levels and different linear velocity relative rotation of theroller, rubber raw materials cut, squeeze its plasticizing, mixing, made to meet therequirements of the production and processing blanks.
Structure:This equipment is consist of Roll, Bearing, Frame, Crossbeam, Driver, The device for regulating the roll gap, Safety device and brake, The device for regulating the temperature, Lubricator etc.
Working Process:Two roller mill (roll) at different speeds (struts. Velocity. Configfile The Velocity) is the relative rotation, the rubber is added to the roller, roller squeeze, due to friction (various friction) and adhesion(coherent force) the role of being drawn into the gap of the tworollers (roll gap), the plastic material in the gap are strongly squeezed (squzze) and shear (shear), so as to achieve the purpose of processing plastic materials. Discharged fromthe roll gap blanks coated ("rolling around) two roller surface velocity and temperature differences in return between the two rollers on a roller, so repeatedly, to complete mixing(milling) role.
Item
Model | Mixing Mill for rubber | XK-160 | XK-250 | XK-360 | XK-400 | XK-450 | XK-550 | XK-560 | XK-610 | XK-660 | XK-710 |
| Rubber sheeting machine | -- | -- | -- | XKY-400 | XKY-450 | XKY-550 | -- | XKY-610 | XKY-660 | XKY-710 |
| Roll diameter | (mm) | 160 | 250 | 360 | 400 | 450 | 550 | 560/510 | 610 | 660 | 710 |
Roll working length
| (mm) | 320 | 620 | 900 | 1000 | 1200 | 1500 | 1530 | 1930 | 2130 | 2200 |
| Front roll linear speed of Mixing mill | (m/min) | 9 | 16.3 | 16.7 | 18.65 | 21.8 | 22.5 | 26.4 | 27.3 | 28 | 31.9 |
| Front roll linear speed of Sheeting machine | (m/min) | -- | -- | -- | 21.9 | 25.6 | 31.7 | -- | 30 | 31.6
30.5 | 30.26 |
| Speed ratio of rolls | Mixing mill | 1: 1.35 | 1: 1.1 | 1: 1.25 | 1: 1.27 | 1: 1.27 | 1: 1.2 | 1: 1.2 | 1: 1.2 | 1: 1.24 | 1: 1.51 |
| Sheeting mill | -- | -- | -- | 1: 1.08 | 1: 1.08 | 1: 1.09 | -- | 1: 1.09 | 1: 1.09
1: 1.13 | 1: 1.09 |
| Max roll space | mm | 4.5 | 8 | 10 | 10 | 12 | 16 | 15 | 15 | 15 | 15 |
| Compound feeding capacity | kg | 1-2 | 10-15 | 2--25 | 18-35 | 50 | 50-65 | 50-65 | 140 | 165 | 190 |
| Motor power | kw | 5.5 | 18.5 | 30 | 45 | 55 | 110 | 90 | 160 | 185/250 | 280 |
| Dimensions | mm | 1133*920*1394 | 2722*1115*1345 | 4200*1780*1855 | 4471*1850*1855 | 5405*1740*1790 | 6646*2736*2105 | 6270*2282*2000 | 6575*2910*1800 | 7280*3400*2530 | 8185*3910*2270 |
| Gross weight | Ton | 2 | 3.2 | 6.5 | 8.3 | 11.4 | 22 | 22.5 | 44 | 49 | 59 |
Mix Mill Overview:
Qingdao Yadong Machinery Group Co., Ltd. is Qingdao Third Rubber Machinery Factory restructuring and the establishment of a private enterprise, was founded in October 1976, with about 40 years history of producing rubber machinery. The company has more than 530 employees, covers an area of 800, 000 square meters, fixed assets 62, 800, 000 yuan, mainly the production of flat vulcanizing machine, mixer, mixing mill, rubber mixing machine, rubber cutting machine, blown film machine, extruder, tires and other rubber products, machine equipment, light truck tires and rubber products. Products obtained in 1988, the production license issued by Ministry of Chemical Industry.
In 1997, we passed the ISO9002 international quality standard certification, the right of self-import, the state two units of measurement, the leading products have won the municipal, provincial Ministry of quality products, the company has was rated as high-tech enterprise in Qingdao City, province of the contract and trustworthy enterprise. In 2003, output value of 183.65 million yuan, sales income of 1, 161, 260, 000 yuan, the profit 3.72 million yuan, tax 5.13 million yuan.
Chairman Mr. Li Tingxi carry the majority of staff sincerely welcome customers to the company to discuss the guide, I would like first-class technology, first-class service, top quality, for your service!
