220kv Angular Electric Power Transmission Tower, Lattice Steel Tower, Transmission Line Tower

Product Specifications

Prod Model:	mz-pt
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Transmission Steel Tower:	Power Transmission Angle Steel Tower
Power Transmission Tension Steel Tower:	Power Transmission Terminal Steel Tower
Suspension Transmission Tower:	Transmission Angle Towers
Steel Tube Poles Tower:	Steel Pipe Combination Towers
Tubular Transmission Tower:	Angle Transmission Tower
Transmission Angle Steel Tower:	Lattice Steel Tower
Lattice Transmission Tower:	Substation Steel Structure
Polygonal Pole Steel Tower:	Galvanized Steel Tower
Overhead High Voltage Transmission Tower:	Steel Transmission Lattice Steel Tower
Power Distribution Tower:	Transmission Steel Tower
Usage:	Branching Tower
Conductor Circuit:	Multi Circuit
Certification:	GS
Materials:	Steel
Standard:	Standard
Style:	Independence Tower
Structure:	Power Transmission Angle Steel Tower

Product Description

Electric Power Transmission Line Steel Tower :
1.  Price Term: EXW, FOB, CFR or CIF.

The price include pole shaft, base plate, crossarm ,anti-climbing device, fasten parts and anchor bolt.
Shipping seaport: Qingdao  Seaport.
Please provide drawings if you have so that we can calculate the accurate price for you.
We also provide design according to your requests, if you don't have drawings.
2.Certificate :ISO 9001:2008,ISO14001: 2004, OHSAS 18001:2007

3. Performance Standard
     Besides conforms to the drawing and design, the materials and fabrication of tower components shall conform to the following standards (Chinese Standards) and customer's requirements.
4. Steel pipe tower welded requirements
1 )we used CO2 welding and submerged arc auto welding or other methods as AWS D1.1
2 )Welded seam shall be full penetration and grinded.
3 )The welded product has no fissure, scar, overlap, layer or other defects.
5. Steel tower Galvanization
All steel items, bolts, nuts, washers & other components to be hot -DIP galvanized with uniform. As per (ASTM-A-123).
5. MOQ: One 40FT Container.
6. Payment Term: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.

7.Delivery Time:  2 weeks per container after PO/drawing/prepayment    confirmed.
8. Package: Normally wrapped by plastical bags ,mat or burlap cloth at the top and bottom,or according to clients requirement.

Type	Straight Pole ,Tensile Pole ,Turn Pole
Suit for	Electricity distribution
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Usually   Q345B/A572, Gr 50,60, 65 minimum yield strength>=345n/mm2 as main material Q235B/ASTM36,minimum yield strength>=235n/mm2- as auxiliary material.
Tolerance of dimension	+- 2%
Power Voltage	10 KV ~500 KV
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Marking	Name plate  through rivert or glue ,engrave ,emboss as per customer requirement
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power ,painting or any other standard by client required.
Joint of Poles/towers	Slip joint connection or flange connection, lattcetype or angle type,
Design of pole	We can design free of charge if Qty is numerous, client should supply the design parameter.
Standard	ISO 9001:2008
Length of per section	Within 14m once forming without slip joint
Welding	Submerged  arc  welding , internal and external double welding makes the welding seam beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Production Process	Raw material test → Cutting→Molding or bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packaging
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.
