Product Specifications
Product Description
Zinc die-cast housing, tin-plated
Excellent quality component, professional circuit design and low loss
0/22KHz signal processed by professional method and compatible with more types of satellite receiver
Select one of two satellite signals through 0/ 22KHz signal supplied from satellite receiver
Utilize one coaxial cable to transmit control signal and satellite signal simultaneously
Item
|
Specification |
Item |
Specification |
|
Frequency Range |
950-2400(MHz) |
Normal Working Voltage |
12-20(V) |
|
Insertion Loss |
3(dB) |
DC Power Consumption |
10(mA) |
|
Isolation |
20(dB) |
DC Max Power Passing |
500(mA) |
|
Return Loss |
8(dB) |
Impedance(all ports) |
75(Ω) |
