Product Specifications
| Prod Model: |
LZZBJ9-24-180b/4 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Indoor: |
CT |
| 24kv: |
Indoor Epoxy Resin |
| Current Transformers: |
Current Transformer |
| Application: |
Switchgear |
| Type: |
Current Transformer |
| Phase: |
Single |
Product Description
LZZBJ9-24-180b/4 current transformers(CT) epoxy resin casting insulation and fully enclosed support construction, encloses primary and secondary windings and annular core in the epoxy resin casting body
The product has the feature of lightweight, omnidirectional installation, withstanding nastiness and dampness
It is widely used for measuring current, electric energy and protective relaying in the electrical system with the rated frequency 50Hz or 60Hz and highest voltage for equipment 17.5(24) kV, IEC61869-1&2
Outline Drawing
